Jeiotech Shaking Incubators Table Top Style
SI-600R
See below for specification on the following models: SI-300 SI-300R SI-600 SI-600R
| Features: |
· Digital PID Microprocessor Controller
· Patented CLS (Custom Logical Sale) System
· Chamber Volume 53L / 83L
· Temperature Control Range : Amb.+ 5.0 ~ 60.0 C (R Type : + 15.0 ~ 60.0C)
· Auto Tuning and Bias Function (Internal Sensor Calibration)
· 99h 59m Temperature Timer with Time Delay ON-OFF function
· Door & Over Temperature Alarms
· 10 to 300 rpm Shaking Speed with Opto-Electronic Feedback
· Shaking amplitude 20, 30 and 40mm (30mm standard)
· Shaking Timer:
- Run time - 10 sec to 999 hr 59 min 59 sec
- Forward & Backward, Pause time - 10 sec to 59 min 59 sec
· Programmable motion - Clockwise, Anti-Clockwise and Pause
· Orbital or Reciprocating motion ( Factory default : Orbital motion.)
· Optional : Universal Platform, Flask Clamp, Spring Wire Rack, Separate Funnel Clamp, Test Tube Rack, Rubber Mat, Sticky Pad, Micro Plate Holder
See below for specification on the following models SI-300 SI-300R SI-600 SI-600R
|
Jeiotech Shaking Incubators SI-300R SI-600R
SI-600R
See below for specification on the following models: SI-300 SI-300R SI-600 SI-600R
| Features: |
· Digital PID Microprocessor Controller
· Patented CLS (Custom Logical Sale) System
· Chamber Volume 53L / 83L
· Temperature Control Range : Amb.+ 5.0 ~ 60.0 C (R Type : + 15.0 ~ 60.0C)
· Auto Tuning and Bias Function (Internal Sensor Calibration)
· 99h 59m Temperature Timer with Time Delay ON-OFF function
· Door & Over Temperature Alarms
· 10 to 300 rpm Shaking Speed with Opto-Electronic Feedback
· Shaking amplitude 20, 30 and 40mm (30mm standard)
· Shaking Timer:
- Run time - 10 sec to 999 hr 59 min 59 sec
- Forward & Backward, Pause time - 10 sec to 59 min 59 sec
· Programmable motion - Clockwise, Anti-Clockwise and Pause
· Orbital or Reciprocating motion ( Factory default : Orbital motion.)
· Optional : Universal Platform, Flask Clamp, Spring Wire Rack, Separate Funnel Clamp, Test Tube Rack, Rubber Mat, Sticky Pad, Micro Plate Holder
See below for specification on the following models SI-300 SI-300R SI-600 SI-600R
|
Shaking features
• Select between orbital or reciprocating action.
• Speed range: 10 to 300 rpm.
• Programmable shaking motion.
- Run time: 10 sec to 999 hr 59 min 59 sec
- Forward & Backward, Pause: 10 sec to 59 min 59 sec
• Maximum orbit size: 70mm dia. (2.8” dia.)
Operating features
• +5°C above room temperature to 60°C for IS-971
+4°C to 60°C for IS-971R
Amb. -15°C to 60°C for IS-971R.
• Microprocess PID control/ Auto-tuning/ Calibration.
• Digital timer: 1 min to 99 hr 59 min, delayed ON/ OFF.
• Over-temperature limiter/ Door opening alarm.
• Digital LED display for temperature (0.1°C resolution), speed, and shaking motions.
• Preset 3 most commonly used temperature settings.
• 9 step temperature and up to 200 cycles of repetition programmable for each profile.
• Adjustable 3 step fan speed with defrosting time / period control.
• RS-232 interface available
Constructional features
• Brushless DC motor for long maintenance-free use.
• High-velocity fans ensure rapid thermal recovery and excellent variation.
• Viewing window in top-opening provides a clear inner chamber view, minimizing the need for opening the
lid. (without IS - 971RF)
• Controlling 5 steps illumination lamp available.(Max. 12,000 lux IS-971RF)
• Gas spring door and lid guards against sudden closures.
• Casters easily makes the unit mobile.
• Door can be secured with a lock and key.
• Use CFC-free refrigerant (for IS-971R, IS-971RF)
Technical Specifications
| |
Model |
IS-971 |
IS-971R |
IS-971RF |
| Temperature |
Range(°C/°F) |
Amb. +5 to 60
/ Amb. +9 to 140 |
+4 to 60
/ +40 to 140 |
Amb -15 to 60
/ Amb -27 to 140 |
Fluctuation 1)
at 25°C,
37°C(R type)
(±°C/°F) |
0.2 / 0.36 |
Variation 1)
at 37°C
(±°C/°F) |
0.8 / 1.44 |
| Refrigerator |
- |
1/3 LBP (AC 120V) |
1/3 LBP (AC 120V) |
| - |
1/6 HBP (AC 230V) |
1/6 HBP (AC 230V) |
Shaking
system |
Motion type |
Orbital or Reciprocating motion selectable |
Frequency
(RPM) |
10 to 300 |
| Timer |
Run time: 10 sec to 999 hr 59 min 59 sec
Forward & Backward, Pause: 10 sec to 59 min 59 sec |
Orbit size
(mm/inch dia.) |
30, 40, 50, 60, 70 / 1.2, 1.6, 2.0, 2.4, 2.8 Available
- Standard 30 / 1.2 |
Recip. stroke
length
(mm/inch) |
30, 40, 50, 60, 70 / 1.2, 1.6, 2.0, 2.4, 2.8 Available
- Standard 30 / 1.2 |
| Dimensions |
Volume
(L/cu ft) |
270 / 9.5 |
Platform
(W×L),
(mm/inch) |
755×481 / 29.7x18.9 |
Internal
(W×L×H),
(mm/inch) |
894×634×480 / 35.2x25.0x18.9 |
Overall
(W×L×H)
(mm/inch) |
1,132×810×1,045
/ 44.6×31.9×41.1 |
1,132×810×1,055
/ 44.6×31.9×41.5 |
Net weight
(Kg/lbs) |
180.0 / 396.8 |
195.0 / 429.9 |
210.0 / 462.9 |
Electrical Requirements
(230V) |
50/60Hz, 5.2A |
60Hz, 7.3A |
50Hz, 7.3A |
60Hz, 9.3A |
50Hz, 9.3A |
Electrical Requirements
(120V) |
60Hz, 11.2A |
60Hz, 13.8A |
60Hz, 17.0A |
Jeiotech Shaking Incubators Floor Style
IS-971 / IS-971R
Features
· Digital PID Microprocessor Controller
· Patented CLS (Custom Logical Safety) System, exceeding DIN Class 2
· Chamber Volume 250L
· Temperature Control Range Amb.+ 5.0 ~ 60.0 C (R Type + 4.0 ~ 60.0C)
· Auto Tuning and Bias Function (Internal Sensor Calibration)
· 99h 59m Temperature Timer with Time Delay ON-OFF function
· Door & Over Temperature Alarms
· Shaking amplitude 30, 40, 50, 60 and 70mm (30mm standard)
· RS 232 with FREE LabTracer Software
· 10 to 300 rpm Shaking Speed with Opto-Electronic Feedback
· Shaking Timer:
- Run time - 10 sec to 999 hr 59 min 59 sec
- Forward & Backward, Pause time - 10 sec to 59 min 59 sec
· Programmable motion - Clockwise, Anti-Clockwise and Pause
· Optional : Flask Clamp, Universal Platform, Spring Wire Rack, Separate Funnel Clamp, Test Tube Rack, Rubber Mat, Sticky Pad, Micro Plate Holder
(SI-600R)
Shaking features
• Select between orbital or reciprocating action.
• Speed range: 10 to 300 rpm.
• Programmable shaking motion.
- Run time: 10 sec to 999 hr 59 min 59 sec.
- Forward & Backward, Pause: 10 sec to 59 min 59 sec
• Maximum orbit size: 40mm dia. (1.6” dia.)
Operating features
• +5°C above room temperature to 60°C for SI-300, 600
15°C to 60°C for SI-300R, 600R
• Microprocess PID control/ Auto-tuning/ Calibration.
• Digital timer: 1 min to 99 hr 59 min, delayed ON/ OFF.
• Over-temperature limiter/ Door opening alarm.
• Digital LED display for temperature (0.1°C resolution), speed, and shaking motions.
• Preset 3 most commonly used temperature settings.
• 9 step temperature and up to 200 cycles of repetition programmable for each profile.
• Adjustable 3 step fan speed.
• RS-232 interface available.
Constructional features
• Brushless DC motor for long maintenance-free use.
• High-velocity fans ensure rapid thermal recovery and excellent variation.
• Gas spring door and lid guards against sudden closures.
• Acryl lid and inner lamp functions allow observation of flask contents.
• Attached fluorescent lamp offered bright observation in a chamber.
• Use CFC-free refrigerant (for SI-300R, 600R)
Technical Specifications
| |
Model |
SI-300 |
SI-300R |
SI-600 |
SI-600R |
| Temperature |
Range(°C/°F) |
Amb. +5 to 60 (Amb. +9 to 140) for SI-300, 600
+15 to 60 (+59 to 140) for SI-300R, 600R |
Fluctuation 1)
at 25°C,
37°C(R type)
(±°C/°F) |
0.3 / 0.54 |
0.6 / 1.08 |
0.1 / 0.18 |
0.2 / 0.36 |
Variation 1)
at 37°C
(±°C/°F) |
1.6 / 2.88 |
1.5 / 2.7 |
0.7 / 1.26 |
0.3 / 0.54 |
| Refrigerator |
|
1/8 HBP (220V,230V) |
|
1/8 HBP (220V,230V) |
| 1/6 HBP (100V,120V) |
1/6 HBP (100V,120V) |
Shaking
system |
Motion type |
Orbital or Reciprocating motion selectable |
Frequency
(RPM) |
10 to 300 |
| Timer |
Run time: 10 sec to 999 hr 59 min 59sec
Forward & Backward, Pause: 10 sec to 59 min 50 sec |
Orbit size
(mm/inch dia.) |
20, 30, 40 / 0.8, 1.2, 1.6 Available - Standard 30 / 1.2 |
Recip. stroke
length
(mm/inch) |
20, 30, 40 / 0.8, 1.2, 1.6 Available - Standard 30 / 1.2 |
| Dimensions |
Volume
(L/cu ft) |
53 / 1.9 |
83 / 2.9 |
Platform
(W×L),
(mm/inch) |
350×350 / 13.8×13.8 |
450×450 / 17.7×17.7 |
Internal
(W×L×H),
(mm/inch) |
410×410×320/ 16.1x16.1x12.6 |
510×510×320/ 20.1x20.1x12.6 |
Overall
(W×L×H)
(mm/inch) |
442×740×622/ 17.4x29.1x24.5 |
540×850×625/ 21.3x33.5x24.5 |
Net weight
(Kg/lbs) |
74.0/163.0 |
85.0/187.0 |
91.0/200.0 |
102.0/225.0 |
Electrical Requirements
(230V) |
50/60Hz,
4.0A |
60Hz,
5.5A |
50Hz,
5.5A |
50/60Hz,
4.0A |
60Hz,
5.5A |
50Hz,
5.5A |
Electrical Requirements
(120V) |
50/60Hz,
7.5A |
60Hz,
10.1A |
50/60Hz,
7.5A |
60Hz,
10.1A |
Jeiotech Incubator Shaker SI-900R
|
Shaking speed : 25 to 250 rpm orbital
Temperature range :
Amb. -10C to 60C
Microprocessor PID control
Digital display and digital output
No noise and no vibration environment
Optional illuminated system
|
|
Microprocessor PID controller offers accurate temperature and shaking speed. Anti-weight flywheel system provides no noise and no vibration environment. Viewing glass window on the lid allows observation of your sample. Possible to change flasks from 50ml to 2L on a universal platform. (up to 30kg workload)
Optional illuminated system. Independent control modules regulate the speed of each shaking unit. Independent control modules regulate the temperature of two incubator chamber unit
|
|
Touch-sensitive membrane keypad with digital display and digital output
|
| Model |
SI-900R |
| Convection type |
Forced air convection with fan motor
|
| Capacity |
216 L |
| Temp. |
Range |
-10? ∼ +60? |
| Accuracy |
±0.1? at 20? |
| Uniformity |
±1.0? at 20? |
| Controller |
|
| Size |
Internal (WxDxH) |
900x600x400 (mm) |
| External (WxDxH) |
1100x700x1100 (mm) |
| Platform (WxD) |
750x470 (mm) |
| Safety |
Over Temp. |
Hydraulic type |
| Electrical |
Over current glass fuse |
| Structure |
Key lock switch |
| Material |
Internal |
SUS #304, 0.8t |
| External |
SS #41, 1.0t, double paint & baked spcc. |
| Tray table |
anodized duralumin #6061, 3.0t(platform) |
| Heater |
Pin type |
| Insulation |
Inflammable polystyrene foam |
| Door |
Double window supported by air-cylinder |
| Shaking |
Method |
Vibration absorbing method, rotation speed can be controlled by feed back system |
| System |
Stroke length |
25 mm, diameter |
| |
Speed/Accuracy |
25 to 250 rpm orbital-shaking / ±1 rpm |
| Max. Load |
10 kg |
250 rpm |
| 15 kg |
250 rpm |
| 20 kg |
250 rpm |
| 25 kg |
200 rpm |
| 30 kg |
200 rpm |
| Motor |
DC motor with photometric feed back control |
| Refrigerator |
1/4 Hp |
| Electric Requirements |
220 VAc, 50/60 Hz |
| Power Consumption |
8.0 A, max |
| Weight(Net) |
200.0kg
|
| These shakers are possible to orbital or reciprocating shaking motion optionally and feature wide shaking speed range from 10 to 300 rpm. Digital opto-electric feedback control system ensures precise and reliable shaking speed so that provide uniform and reproducible experiments. LED indicates time and set and actual shaking speed.
It is possible to forward or backward orbital, or reciprocating shaking motion and pause at a same position with timer. Also, it can be programmed in combination with forward/backward shaking motion, pause and time. Pause at a same position function is patent pending.
With brushless DC motor and anti-weight fly wheel system the noise and vibration is reduced considerably. You can choose from a wide variety of accessories, as universal platform accommodated with 50ml to 2000ml flask clamps(clamps sold separately), universal attachment, spring wire rack, test tube attachment and rubber mat.
|
| |
 |
|
Test tube attachment
|
 |
|
Spring wire rack
|
 |
|
Flask clamps(50ml to 2000ml)
|
|
 |
|
Shaker
|
|
 |
|
Control
|
|
|
| Model |
SK-300 |
SK-600 |
SK-71 |
Shaking
system |
Type |
Orbital (forward, backward), Reciprocating (Optional) |
| Shaking range |
10 to 300 rpm |
| Accuracy |
± 1 rpm |
| Stroke length |
20, 30, 40 mm |
20, 30, 40, 50 mm |
30, 40, 50, 60, 70 mm |
| Method |
Brushless DC motor drive |
| Control |
Digital opto-electric feedback control |
| Timer |
999 hours 59 min. |
| Indication |
Program, timer, rpm digital indication |
| Material |
Body |
SS #41, 3.2t & 2.0t, double paint & baked |
| Platform |
Anodize duralumin #6061, 4.0t |
| Permissible ambient temperature |
+ 5 ? to 50 ? |
| Size |
External (WxDxH) |
410 x 470 x 140 (mm) |
510 x 575 x 140 (mm) |
820 x 605 x 140 (mm) |
| Platform (WxD) |
350 x 350 (mm) |
450 x 450 (mm) |
750 x 475 (mm) |
| Weight(Net) |
24.0 kg |
29.0 kg |
54.0 kg |
Electrical Requirements
Code No. |
110V 50/60Hz, 0.4A
31106 |
110V 50/60Hz, 0.4A
31206 |
110V 50/60Hz, 0.4A
31306 |
Electrical Requirements
Code No. |
220V 50/60Hz, 0.2A
31105 |
220V 50/60Hz, 0.2A
31205 |
220V 50/60Hz, 0.2A
31305 |
Jeiotech Non Incubating Shaker SK-760
| SK 760 series have orbital shaking motion and shaking speed from 25 rpm to 350 rpm. It is also possible to reverse shaking. Microprocessor PID-A controller offers accurate shaking speed. Touch-sensitive membrane keypad with digital display and digital output. Anti-weight flywheel system eliminates noise and vibration environment. It is possible to change flasks from 50 ml to 2 L on a universal platform (upto 30 kg workload) and is easy to change variable shaking attachment. You can save the space with four stages shaking system that hold up to four shakers in a single rack optional (see letf page). With auto start and stop function you can start or stop to run when you want. |
 |
|
Shaker SK-760 series with SA-1 universal attachment and flask clamps
|
|
 |
|
Touch-sensitive membrane keypad with digital display and digital output
|
|
| Model |
SK-760A |
SK-760B |
SK-760C |
| Shaking type |
Orbital |
Orbital |
Orbital |
Shaking
system |
Method |
Belt drive with fly wheel |
| Stroke length |
25 mm |
38 mm |
50 mm |
| Speed |
25 to 250 rpm |
| Accuracy |
± 1 rpm |
| Control |
Digital PID - Autotuning |
| Timer |
Auto / start-stop double function |
| Size |
External (WxDxH) |
780x590x150 (mm) |
| Platform (WxD) |
750x470 (mm) |
| Max. Load |
10 kg |
250 rpm |
250 rpm |
250 rpm |
| 15 kg |
250 rpm |
250 rpm |
250 rpm |
| 20 kg |
250 rpm |
230 rpm |
230 rpm |
| 25 kg |
200 rpm |
210 rpm |
200 rpm |
| 30 kg |
200 rpm |
170 rpm |
150 rpm |
| Material |
Body |
SS #41, 3.2t & 2.0t, double paint & baked spcc. |
| platform |
Anodized duralumin #6061, 4.0t, 50ml ∼ 2L, universal type |
| Platform |
Interchangeable platform and flask holder |
| Motor |
Plate type DC motor |
| Electric Requirements |
220 VAc, 50/60 Hz |
220 VAc, 50/60 Hz |
220 VAc, 50/60 Hz |
| Weight(Net) |
54.0 kg |
54.0 kg |
54.0 kg
|
Jeiotech Benchtop Shaking Incubators
SI-300R & SI-600R
| Features
· Digital PID Microprocessor Controller
· Patented CLS (Custom Logical Sale) System
· Chamber Volume 53L / 83L
· Temperature Control Range : Amb.+ 5.0 ~ 60.0 C (R Type : + 15.0 ~ 60.0C)
· Auto Tuning and Bias Function (Internal Sensor Calibration)
· 999hr. 54min. Temperature Timer with Time Delay ON-OFF
· Door & Over Temperature Alarms
· 10 to 300 rpm Shaking Speed with Opto-Electronic Feedback
· Shaking amplitude 20, 30 and 40mm (30mm standard)
· 999h 59m Shaking Timer
· Programmable motion - Clockwise, Anti-Clockwise and Pause
· Orbital or Reciprocating motion ( Factory default : Orbital motion.)
· Optional : Universal Platform, Flask Clamp, Spring Wire Rack, Separate Funnel Clamp, Test Tube Rack, Rubber Mat
|
