Features
A complete solution
All included, in the right place: this is the philosophy underlying this instrument. XDS-2 is equipped with a full series of objectives, that covers most standard applications. The translating stage is included in the standard equipment, and so is a set of 4 objectives (4x and 40x for brightfield; 10X and 20X for phase contrast).
Ergonomy
Every control is easy to reach, every component has been designed with ease of use in mind. The focusing and specimen translation controls are designed to allow to rest the wrists on the table. The light intensity regulation is placed very close to the focusing knobs. The specimen stage is fitted with a special glass insert, that allows to see the objectives, for immediate identification of the magnification setup. The head implements an extremely innovative design, that permits adjustment to compensate for operator height.
Efficiency
Plan-achromatic infinity corrected optics, bright 30W halogen illuminator, phase contrast sets, holders for specimen slides, flasks, Petri dishes, trinocular head for photo/video applications. These are the features of XDS-2, a powerful, complete and innovative instrument, designed to set a reference standard for advanced routine microbiology.
Technical Information
| Model: |
XDS-2 |
| Optical system |
Infinity corrected system, 45 mm parafocality distance. Field of view 22 mm. |
| Heads |
Trinocular: 30° inclined, 360° rotating. Interpupillary
distance: 48 - 75 mm.
Adjustable dioptric compensation.
Ergonomic height compensation. |
| Eyepieces |
Extra-wide field EWF10x/22mm, eyeglass-compatible. |
| Nosepiece |
5 positions, with bidirectional rotation on ball bearings and click stop. |
| Objectives |
Long working distance (LWD) infinity corrected (IOS)
planachromatic: 4x/0.10 (working distance 18 mm), phase contrast 10x/0.25 (working distance 10 mm), phase contrast 20x/0.40 (working distance 5.1 mm), 40x/0.60 (working distance 2.6 mm), corrected for 1.2 mm coverglass. |
| Specimen stage |
Size: 250 x 230 mm. Translator with lowered ergonomic coaxial controls. X-Y translation: 119 x 70 mm.
Interchangeable metallic inserts for specimen slides, Petri dishes and flasks. |
| Focusing system |
Macro and micrometric regulation, with coaxial knobs on both sides of the stand.
Adjustable friction. |
| Condenser |
Long working distance condenser, numerical aperture 0.30, working distance 72 mm.
The condenser can be removed in order to increase the working distance to 150 mm. |
| Illumination system |
6V / 30W halogen precentered illuminator, with adjustable intensity, filter and phase ring holder and aperture diaphragm.
|
|
