UVsafe Ultraviolet Safetywear



As ultraviolet radiation can be dangerous for unprotected eyes and skin, UVItec recommends its range of safety wear. All produced to fully meet international safety standards for UV blocking. Our safety wear is recommended to all operators of ultraviolet equipment and patients after PUVA treatment. Cover spectacles and face shields are specially produced for UVItec by Bollé, the leading European eye safety wear manufacturer.



• comfortable to wear
• Lightweight, unobtrusive design
• Guaranteed to completely block ultraviolet radiation below 400nm
• CE marked

Ordering

SS 350	UV safety cover-specs
SG 550	UV safety goggles
SF 850	UV face shield

UVP XX Series Bench Ultraviolet Lamps

				Bench XX-Series family offers a complete selection of models - fixture only or two tubes each of the following wavelengths: longwave, BLB (black light blue), shortwave or midrange. Shortwave ultraviolet (254nm) radiation offer reliable and effective tool for sterilization and sanitation applications in hospitals, laboratories, pharmaceutical companies and clinics.
Key Features: Brackets are included for ceiling or wall mounting Various fixture sizes and wavelengths are available Lamps are manufactured with a durable aluminium housing and powder paint finish Scratch resistant Shortwave lamps can be used in an upward facing position for purifying air or in a downward position for sanitizing work surfaces 254nm UV lamps can kill up to 99% of organisms from bacteria, yeast, mould spores, germs and viruses UV intensity can be increased by bringing the lamp closer to object being sterilized
Exposure Stand		The XX-15 Lamp connects to the new Exposure Stand which provides a platform for UV fluorescence experimentation. The shelf is adjustable to different levels for repeatable exposure of samples.
XX-20 Lamp Dimensions: 24"L x 6"W x 4.25"H (610 x 152 x 108mm); Weight: 10 lb (4.5 kg)  XX-40 Lamp Dimensions: 49.6"L x 6"W x 4.25"H (1260 x 152 x 108mm); Weight: 20 lb (9.0 kg) XX-15 Lamp Dimensions: 19.75"L x 6"W x 4.2"H (502 x 152 x 108mm)Weight: 5 lb (2.3kg)  Exposure Stand Dimensions: 20"L x 6"D x 14"W (508 x 152 x 330mm)Weight: 8 lb (3.6 kg)
Ordering Information:
Model Part Number Description Volts XX-15 95-0042-03 XX-15 Bench Lamp Fixture (no UV source) 115 XX-15 95-0042-02 XX-15 Bench Lamp Fixture (no UV source) 220 XX-15BLB 95-0042-06 XX-15BLB Bench Lamp, LW BLB 365nm 115 XX-15BLB 95-0042-11 XX-15BLB Bench Lamp, LW BLB 365nm 230 XX-15S 95-0042-05 XX-15S Bench Lamp, SW 254nm 115 XX-15S 95-0042-09 XX-15S Bench Lamp, SW 254nm 230 XX-15L 95-0042-07 XX-15LW Bench Lamp, LW 365nm 115 XX-15L 95-0042-13 XX-15LW Bench Lamp, LW 365nm 230 XX-15M 95-0042-08 XX-15MR Bench Lamp, MR 302nm 115 XX-15M 95-0042-15 XX-15MR Bench Lamp, MR 302nm 230 XX-20BLB 95-0045-04 XX-20BLB Bench Lamp, LW BLB 365nm 115 XX-20BLB 95-0045-05 XX-20BLB Bench Lamp, LW BLB 365nm 230 XX-20S 95-0045-07 XX-20S Bench Lamp, SW 254nm 115 XX-20S 95-0045-08 XX-20S Bench Lamp, SW 254nm 230 XX-20 95-0045-01 XX-20S Bench Lamp, No Tubes 115 XX-20 95-0045-02 XX-20S Bench Lamp, No Tubes 230 XX-40BLB 95-0043-04 XX-40BLB Bench Lamp, LW 115 XX-40BLB 95-0043-05 XX-40BLB Bench Lamp, LW 230 XX-40S 95-0043-07 XX-40S Bench Lamp, SW 115 XX-40S 95-0043-08 XX-40S Bench Lamp, SW 230 XX-40 95-0043-01 XX-40 Bench Lamp, No Tubes 115 XX-40 95-0043-02 XX-40 Bench Lamp, No Tubes 230 Exposure Stand XX-Stand 18-0062-01 XX-15 Exposure Stand N/A



UVP VisionWorksLS Analysis Software

New! VisionWorks®LS Image Acquisition and Analysis Software is designed as a sophisticated software package for 1D analysis of gels, plates and membranes as well as colony counting. The user friendly software functions feature: Image Acquisition Controls Advanced Analysis Tools Fluorescence Calibration Instrument One-Touch Macros Support for 21 CFR Part 11 Compliance Extensive Image Enhancement Capabilities User Defined Profiles and Preferences Detailed Report Generation













Image Acquisition
The VisionWorks®LS image capture function is configured to work with UVP’s BioImaging Systems.  Capture images of any fluorescently labeled or colorimetric stained gels, blots, and membranes. For chemiluminescent imaging, acquire chemiluminescent Western, Northern and Southern blot images without using radioisotope labeled 32P and film. The user friendly software guides you through steps for capture of images. Integration options: On-chip integration for the simplest image capture; convert “live image preview” to captured image with one keystroke Sequential integration for automatic sequence of images of increasing exposure to ensure captured picture with optional exposure times; features automatic Digital Video Playback (DVP) of acquired images Dynamic integration for special sequential capture of Western Blots; each image is an addition of previous exposures so that an optimal picture can be formed in the minimum time before the chemiluminescence fades
Dynamic Integration demonstrates blotting with substrates of high  signal but limited duration and low background (e.g. ECL Plus).
	Saturation Warning  Assure imaging results are quantifiable by using the saturation warning to to detect saturation of bands in live preview.
1D Lane Densitometry/Analysis
VisionWorks®LS analysis software includes comprehensive tools to provide a full range of analysis capabilities. VisionWorks®LS enables image acquisition and analysis for a wide range of applications including chemiluminescence, chemifluorescence, fluorescence, bioluminescence, colorimetric, live animal and in vitro samples. The easy to use functions automate your experiment analysis with accurate quantitation, generation of lane profile graphs, plus intensity histograms, concentration curves and much more!
Applications:
Protein Quantitation   Quantitative PCR   cDNA Differential Expression   GFP Expression Analysis   FISH Analysis   Gel Scoring   PCR Gene Expression   Colony Counting   TLC Analysis   Dot Blot Analysis   and more!
Maximizing Fluorescence Calibration
New! Using a non-photobleaching fluorescent standard step tablet placed on a FirstLight UV Illuminator, users can normalize the control and treatment regions (bands and spots) on acquired images again one another for varioution in lighting and optical conditions.  Images taken with the steptab can be analyzed with sophisticated statistics including mean and standard deviation, modified entropy and volume.
One-Touch Automated Macros
		Create your own macros to automate time consuming routine procedures involving image capture, enhancement, analysis and data archiving. Assign a function key to recorded macros for one-touch automation.
Support for 21 CFR Part 11 Compliance
VisionWorks®LS Software supports image security and change logs to assist with 21 CFR Part 11 compliance. Track image and analysis history and show image properties and user comments Control of account set-up by Administrator, determine usernames and passwords, as well as permissions for viewing and editing images Maintain login history of all accounts
Image Enhancement Capabilities
VisionWorks®LS offers many image enhancement features, process filters and annotation capabilities as non destructive tools for visualization and publication (click links for screen images). Enhance images with brightness, contrast, gamma, emboss, invert and pseudo color Annotate with text, lines, arrows, ellipse, and highlighter tools; show, hide or burn into image Select from filters to sharpen, blur and remove frequency based noise, 3D Image Profiler
User Profiles and Preferences
Researchers can personalize their workspace by placing tool bar icons along the side or across the top, with or without text. Then save the profiles by user name. Set up user accounts with passwords to protect user data. Tool bar layout preferences can be saved for different users.
Profile Menu  For set up of multiple users and experiment preferences.
Report Generation
Save images as various file formats including TIFF, JPEG, BMP, TGA, PNG and GIF for use in presentations or documentation Create detailed and user-configured reports showing extensive analysis results on MW, Rf, precise position of bands, band intensities, etc. Use the Filter Data button to choose specific data for reports Configure the Qwik-Link icon to automatically open an external software application Export data to Microsoft Excel or simple-text using Dynamic Data Exchange (DDE)
Ordering Information VisionWorks®LS Image Acquisition and Analysis Software Minimum System Requirements: Windows 2000 SP4,  Windows XP Pro SP1 or later 97-0186-02 Single 97-0186-03 Network Steptab, Fluorescent Calibration Standard,  21 step, 0.5” x 5.0” (1.27 x 12.7mm) 33-0014-02

Gel Documentation Systems - UVP

Economical system combines the processor, LCD screen and camera with a mini hood or camera stand for gel documentation of fluorescent and colorimetric samples. Unique configuration is excellent for multiple user laboratories. A computer is not required; however, network connectivity is possible for transfer of images directly to your computer.  Main Features  •Fluor CCD camera with zoom lens  •View images on the LCD screen which pivots for optimum viewing angle  •Built-in processor with touch pad controls the camera integration, image exposure and file save options  •Save images in 8 or 12-bit TIFF or 8-bit JPG formats to the CompactFlash memory card or transfer images via network connectivity  •Select from a mini hood or camera stand to complete the system  •EtBr filter included  •Transilluminator is optional VisiDoc-It Hood  •Mount the camera to the mini hood to create a darkroom environment  •The camera connects to the processor for image capture and saving capabilities  •Transilluminator is optional VisiDoc-It Stand  •Mount the camera to the stand which is positioned over the platform  •The camera connects to the processor for image capture and saving capabilities  •Transilluminator is optional Touch Pad Controls  •Six button touch pad controls live preview, integration settings, capture, save and set-up functions  •Screen shows image in FRZ capture mode   Technical Information Camera: •Fluor Camera (200) Mini hood or Stand: •Lightweight hood fits on top of the transilluminator (optional)  •Camera connects to the stand which positions the camera over the transilluminator (optional) Emission Filters: •EtBr Red 570-640nm Dimensions: •Processor 5H x 14.1W x 12.7D in. (127 x 358 x 323mm)  •Hood: 16H x 12.4W x 9.4D in. (406 x 315 x 239mm)  •Stand: 18.5D x 19.8W x 32.5H in. (457 x 503 x 826mm)



UVIvue Ultraviolet Transilluminator



• Widest range available

• Superb quality

• Electronic ballast now as standard*

• Stainless steel filter frames and longlife filters

• Dual wavelength combinations

•  UV blocking cover

*(exception of dual wavelength & white light)

For the optimum visualisation of agarose or polyacrylamide gels, UVItec offers what is probably the widest available range of ultraviolet transilluminators. The ‘mini’ range takes 8W tubes and can have filter sizes up to 21 x 26cm. With the standard sized range, filter sizes up to 20 x 40cm are possible. All models are of superb quality with stainless steel filter frames, longlife filters and highly polished ‘ondulex’ reflectors for ultimate efficiency. An adjustable UV blocking cover is included to protect the user from harmful UV. The range now includes electronic ballast technology as standard with the exception of the dual wavelength and the white light models. This new technology reduces flicker, provides instant switch on and allows dual intensity to be a standard feature.

Extensive range

There are more than 30 models in the entire UVItec range, including two sizes of unit (mini and standard), five sizes of viewing filter and three different wavelength ranges. Mini units (BXT, BTS) have a small footprint of 34 x 26cm while standard units (SXT, STS) have a footprint of 47 x 33cm. Filter sizes of 15 x 15cm, 20 x 20cm and 21 x 26cm are available for mini units while standard unit filters can be up to 20 x 40cm. Wavelength ranges of maximum 254nm, 312nm and 365nm are available as well as dual wavelength and white light models.

Highest performance

The highly polished ‘ondulex’ reflectors positioned behind the UV tubes give the highest possible efficiency of UV output, superior to that achieved by plain aluminium. The filter material is also chosen for maximum transmission of the chosen wavelength range as well as long life usage (unlimited at 365 and 312nm, up to 3000 hours at 254nm).

Designed for rough treatment



The high quality, stainless steel filter frame is resistant to chemicals and scratching. The epoxy painted body is also chemical resistant and the unit design eliminates leakage of liquids into the interior.

Facilitates gel handling

The transfer and positioning of wet gels onto the transilluminator surface is facilitated by the smooth, scratch resistant stainless steel filter frame and the highly polished filter surface.

The angle-adjustable UV blocking cover offers hands-free protection to users from the harmful UV rays.

Space saving

 The mini units offer efficient, high-powered UV illumination of gels and blots up to 21 x 26cm in size, while having a footprint of only 34 x 26cm. What is more, the mini sized dual wavelength models allow illumination in two different wavelengths from a single compact unit. A dual UV/white light model is also available for illumination of fluorescent and visible gels of up to 20 x 20cm.

ultravue transilluminator

The use of special filter material in the Ultravue transilluminator greatly enhances contrast, making fluorescent bands easier to see both by eye and with documentation systems such as UVIsave, UVIdoc and UVIpro. The special filter eliminates visible light output thereby reducing the need for filtering to isolate the fluorescent band signal.



Enhanced viewing with ethidium and sybr® stains

Gels stained both with ethidium bromide and with sybr® green are viewed by eye more easily on the Ultravue transilluminator. Since background light is eliminated, no filtering is required, and no signal is lost. The dark, uniform filter surface provides a high contrast background enabling viewing of even the faintest bands.



Enhanced documentation

The absence of visible background light and minimal IR output from the Ultravue transilluminator enable broad transmission camera filters to be used. This ensures that maximum transmission of the fluorescent signal is always achieved. For sybr® green documentation, Ultravue is preferable to visible (blue light) illumination in which a large part of the signal is always lost while filtering out the blue background light.

Ordering

Ultravue Transilluminator

Model	Description	Filter (cm)	Tube	Wavelength (nm)
UTX 20M	Hi/Lo Intensity	20 x 20	6 x 8W	312



UVIvue Transilluminator (standard size)


Model	Description	Filter (cm)	Tube	Wavelength (nm)
SXT 20S	Hi/Lo Intensity	20 x 20	6 x 15W	254
SXT 20M	Hi/Lo Intensity	20 x 20	6 x 15W	312
SXT 26S	Hi/Lo Intensity	21 x 26	6 x 15W	254
SXT 26M	Hi/Lo Intensity	21 x 26	6 x 15W	312
SXT 35S	Hi/Lo Intensity	20 x 35	6 x 15W	254
SXT 35M	Hi/Lo Intensity	20 x 35	6 x 15W	312
SXT 35L	Hi/Lo Intensity	20 x 35	6 x 15W	365
SXT 40S	Hi/Lo Intensity	20 x 40	6 x 15W	254
SXT 40M	Hi/Lo Intensity	20 x 40	6 x 15W	312
STS 20WL	Single Intensity		dual	wavelength
		20 x 20	6 x 8W   2 x 8W	365     White Light
STS 20WS	Single Intensity		dual	wavelength
		20 x20	6 x 8W  2 x 8W	254   White  Light
STS20WM	Single Intensity		dual	wavelength
		20 x 20	6 x 8W  2 x 8W	312     White   Light
STS 35W	Single Intensity	20 x 35	4 x 8W	White Light



UVIvue Transilluminators (mini size)

Model	Description	Filter (cm)	Tube	Wavelength (nm)
BXT 15S	Hi/Lo Intensity	15 x 15	4 x 8W	254
BXT 15M	Hi/Lo Intensity	15 x 15	4 x 8W	312
BXT 15L	Hi/Lo Intensity	15 x 15	4 x 8W	365
BTS 20W	Single Intensity	20 x 20	2 x 8W	White Light
BXT 20S	Hi/Lo Intensity	20 x 20	6 x 8W	254
BXT 20M	Hi/Lo Intensity	20 x 20	6 x 8W	312
BXT 20L	Hi/Lo Intensity	20 x 20	6 x 8W	365
BXT 26S	Hi/Lo Intensity	21 x 26	6 x 8W	254
BXT 26M	Hi/Lo Intensity	21 x 26	6 x 8W	312
BTS 20LM	Single Intensity		Dual	Wavelength
		20 x 20	6 x 8W  5 x 8W	365  312
BTS 20MS	Single Intensity		Dual	Wavelength
		20 x 20	6 x 8W  5 x 8W	312  254
BTS 20LS	Single Intensity		Dual	Wavelength
		20 x  20	6 x 8W  5 x 8W	365  254
BTS 26LM	Single Intensity		Dual	Wavelength
		21 x 26	6 x 8W  5 x 8W	365  312
BTS 26MS	Single Instensity		Dual	Wavelength
		21 x 26	6 x 8W  5 X 8W	312  254
BTS 26LS	Single Intensity		Dual	Wavelength
		21 x 26	6 x 8W  5 x 8W	365  254



UVItec Replacement Ultraviolet Tubes and Thermal Paper

Ultraviolet Tubes



UVItec can supply a full range of ultraviolet tubes to fit most available models of UV transilluminator and UV lamp, plus other UV devices. We specialise in rapid delivery from extensive stocks. We also offer discounts for purchase of multiple (5+) tubes.

In addition to those listed in the table, we can also supply larger UV tubes of up to 40W including short wave (254nm) germicidal tubes.

Please contact us for details.

Ordering

Model No.	Output (watts)	Wavelength
T4L	4W	365
T4S	4W	254
T4LN	4W	365 BLB
T6L	6W	365
T6S	6W	254
T6M	6W	312
T6LN	6W	365 BLB
T6LS	6W	254 BLB
T8L	8W	365
T8S	8W	254
T8M	8W	312
T8LN	8W	365 BLB
T15L	15W	365
T15S	15W	254
T15M	15W	312
T15LN	15W	365 BLB



Mitsubishi Thermal Paper



UVItec can supply Mitsubishi thermal paper which can be used in both Mitsubishi and Sony thermal printers.

Order Code	Paper Type
K65HM	high density
K91HG	high gloss

UVItec Chemiluminescence Imaging Introduction

UVItec proudly introduces two ultra-high performance imaging systems for chemiluminescence and fluorescence documentation.  Both systems have unrivalled sensitivity and resolution.

The UVIchemi is a high end dedicated chemiluminescence documentation system for users who require fast and accurate detection with no sacrifice in sensitivity or quality.


The UVIprochemi system superbly combines ultra-high sensitivity chemiluminescence and fluorescence documentation in a flexible system. A set of filter options and overhead (epi-) UV and white light illumination ensure that the system can be optimised for a number of different fluorescent applications.




Our ultra sensitive, cooled CCD camera means that chemiluminescence images can now be captured easily, utilising the full resolution of the camera. Binning mode, which is often used to increase the sensitivity of a camera (but greatly decreases image resolution) is no longer necessary. Both systems have a unique additional cooling system for handling high ambient temperatures.

Recent improvements in cooled CCD camera technology have resulted in a great leaps forward in both sensitivity and resolution. Chemiluminescence documentation has now come of age and offers applications such as accurate quantification that were not previously available when using X-ray film.

At UVItec we quickly recognised that chemiluminescence places unique demands on an image documentation system. Conventional CCD cameras are unsuited to the rigors of chemiluminescence documentation. Chemiluminescent reactions often produce an extremelyweak light signal that requires far longer exposure times than are necessary for conventional fluorescence documentation. Due to the properties of CCD sensors, long exposure times mean that heat generated by electronic circuitry of the camera cause the background noise levels to increase with the exposure time.  Deep cooled CCD cameras are therefore used to eliminate the high levels of background. Our tests have shown that the UVItec deep cooled CCD camera produces negligible noise levels even at exposures of over 30 minutes.

Major Advantages of Chemiluminescence CCD documentation are:


• Sensitivity - CCD systems are more sensitive than X-ray film
• Quantification- our analysis software enables quantification of chemiluminescence samples

• Elimination of radioactivity - In many cases, hazardous and expensive radioactive protocols can be replaced with chemiluminescence without sacrificing sensitivity

• Simplicity and Speed - shorter exposure times and ‘one click’ image acquisition reduce the amount of time spent acquiring an image



UVIspot 2D Analysis Software

The inexpensive 2D alternative



•  Comprehensive 2D analysis at a 1D price

•  Automatic detection of ‘matched’ spots

•  Gel comparison by spot movement, volume variations and presence/absence

•  Comparison of up to 256 gels in one experiment

•  Up to 9 parameter spot characterisation

•  Searchable database for easy archiving and comparison



• Rapid, accurate and intuitive

• Straightforward, stepwise analysis – no gimmicks

• Attractive, smart user interface

• Automated steps with optional user editing



UVIsoft Gel Analysis Family



Special Features and Benefits

In designing UVIsoft analysis software, we have thought of everything. As a result, all UVIsoft analysis packages are:

User-Friendly: every aspect of UVIsoft is designed with ease of use in mind. This includes the very first step of opening an image, which is facilitated by the ability to choose the file from a “thumbnail” image gallery.



Powerful: all UVIsoft analysis  packages include the option of reliable, fully automatic background subtraction for band quantification and optional methods for correction of gel distortions during molecular weight calculations.



Flexible: Attractive as it may sound, “One Step” analysis places excessive reliance on automation and can detract from accurate gel or blot analysis. Analysis in UVIsoft packages is step-wise and at each analysis step, there is the facility for the user to check and (if necessary) edit the results of automatic analysis processes.





Versatile: In addition to the incredibly broad range of analysis functions available in UVIsoft, there are also functions to facilitate data presentation, reports and posters. The “Print Designer” function enables data tables plus images from all analysis fields to be automatically “pasted” into a presentation or report along with explanatory text. The report can then be saved as a template, so the same report can be prepared from other data.





UVIsoft Chemiluminescence Acquisition System for UVIchemi & UVIprochemi

The UVIchemi and UVIprochemi acquisition software facilitates simple and rapid optimisation of images when long exposures are necessary. Automatic exposure mode makes it possible to acquire fully optimised images of the very faintest samples at the push of a button. Varying levels of user control over the image acquisition process are offered by the semi-automatic and manual exposure modes. Acquisition parameters can be saved in configuration files for future use and are automatically saved with each image in a secure GLP file. The attractive software interface features large colour coded buttons and self-evident icon designs to minimise the user learning curve. The UVIprochemi software also includes zoom lens controls and a saturation monitor function.

• Easy to use with Windows® XP style software interface
• Automatic exposure control
• Video mode for sequential capture
• Save individual user settings
• Image saturation monitor
• GLP file automatically saved with each image



More Software Details

• Automatic Exposure mode automatically calculates the exposure time so that the image can be captured in one simple "click".

• Manual Exposure mode allows the user the set their own exposure time. From 1/10th of a second up to 120 min

• Test Function detects when the signal produced by the Chemiluminescent reaction is intense enough for an exposure to be made.

• Video mode enables the user to monitor the progress of a Chemiluminescent reaction by taking a series of exposures at user defined intervals

• Annotation function allows text as well as the date and time to be added to the image

• Positive/Negative button allows viewing an ‘inverted’ image

• Live mode enables easy positioning of the sample

• The UVIprochemi software includes controls for the motorised zoom lens enabling the user to automatically adjust the aperture, zoom and focus settings from the software screen

• Good Laboratory practice (GLP) function. A GLP file is automatically saved with each image file. The user can input an experiment title, comments and the camera settings. All post-capture image modifications and processing are recorded automatically

• Temperature control indicator helps to ensure that the camera is always at the correct operating temperature

UVIsave Gel Documentation System



All the flexibility of an instant photography system, combined with the speed, versatility and precision of a video documentation system. Works with any UV or white light transilluminator. Simply place camera hood over gel, optimise image whilst viewing it on the built-in 5.6" LCD screen, freeze image, then print to video printer or save on compact flash.

Unlike instant photography and digital camera systems, video documentation systems allow the optimisation of your gel image before you produce a print. This means no more wastage of time and expensive photographic film while you attempt to produce the best possible image. With UVIsave, you can adjust zoom, aperture, focus and exposure time and see the effects of the adjustments before image capture. This reduces the cost of an optimised image ‘hard copy’ from as much as several pounds with instant photography, to a few pennies with UVIsave. Also, since you can see an instant preview of any image adjustments, the entire process takes only seconds.  What is more,

UVIsave includes a compact flash drive, which allows the captured image to be saved as a computer file (TIFF format), opening up a huge range of modification, printing and analysis options. UVIgeltec software is supplied for this purpose.



• The world’s simplest documentation system - now even better!

• Portable and versatile with no compromise on quality


• Flexible – use with any transilluminator

• Ultra-compact, rapid and easy to use


• Now with 5.6" LCD screen and compact flash



UVIprochemi Chemiluminescence Imaging System



Acquisition Software

• Versatile Imaging system – Fluorescence and Chemiluminescence



• Overhead (epi-) UV and white light illumination

• Pull-out transilluminator with safety override for UV

• Motorised zoom lens with GLP feedback

• Filter wheel for multi-application usage

• Automatic exposure mode for easy image acquisition

• Unique additional system cooling for laboratories with high ambient temperatures


UVIprochemi is a versatile imaging system that handles both chemiluminescent and fluorescent imaging applications with ease. The high quality, light-tight darkroom cabinet incorporates a transilluminator on a pull-out drawer, a 3-position filter wheel and a software driven motorised zoom lens. The UVIprochemi is the perfect solution for laboratories with a range of demanding imaging applications. The exceptional camera resolution allows closely spaced bands to be easily resolved while the high quantum efficiency ensures that the faintest bands can be detected and accurately quantified. The system also includes UV (254 and 365nm) and white light epi-illumination for applications such as TLC. The filter wheel enables the use of multiple filters for more specialised fluorescent labels. The UVIprochemi handles all standard chemiluminescence, fluorescence and densitometric applications including:



Western blots, Southern and Northern, Blots Dot/Slot Blots, MTP assays, TLC, Colony Plates





While some of our competitors who claim to use TRUE "16 bit" output from cameras with inferior performance, we at UVItec prefer to use a the top of the range 12 bit camera with REAL 12-bit performance, meaning ultra low noise and exquisite sensitivity.


UVIprochemi components:

• Light tight darkroom with super efficient locking mechanism.

• Pull out transilluminator with UV safety override feature for band excision

• Fully enclosed camera housing with unique additional forced air Peltier cooling device

• Class leading, high sensitivity 12-bit camera with 3 stage Peltier cooling

• Filter slide with a range of optional filters for different applications

• Motorized zoom lens controlled via software

• Epi-illumination - white light and UV

• Robust metal construction ensures reliability in multi-user environments

• Image acquisition using UVIprochemi software via PCI interface

• Optional digital thermal printer can be used
• Optional Epi Bright LED Illumination system can be used for protein detection


UVIprochemi operation



All aspects of the UVIprochemi operation are fully automated, the motorized zoom is controlled directly from the PC so there is no need to touch the camera during normal operation.



Acquisition Software

UVIsoft for UVIchemi & UVIprochemi

The UVIchemi and UVIprochemi acquisition software facilitates simple and rapid optimisation of images when long exposures are necessary. Automatic exposure mode makes it possible to acquire fully optimised images of the very faintest samples at the push of a button. Varying levels of user control over the image acquisition process are offered by the semi-automatic and manual exposure modes. Acquisition parameters can be saved in configuration files for future use and are automatically saved with each image in a secure GLP file. The attractive software interface features large colour coded buttons and self-evident icon designs to minimise the user learning curve. The UVIprochemi software also includes zoom lens controls and a saturation monitor function.



• Easy to use with Windows® XP style software interface
• Automatic exposure control
• Video mode for sequential capture
• Save individual user settings
• Image saturation monitor
• GLP file automatically saved with each image





More Software Details

• Automatic Exposure mode automatically calculates the exposure time so that the image can be captured in one simple "click".

• Manual Exposure mode allows the user the set their own exposure time. From 1/10th of a second up to 120 min

• Test Function detects when the signal produced by the Chemiluminescent reaction is intense enough for an exposure to be made.

• Video mode enables the user to monitor the progress of a Chemiluminescent reaction by taking a series of exposures at user defined intervals

• Annotation function allows text as well as the date and time to be added to the image

• Positive/Negative button allows viewing an ‘inverted’ image

• Live mode enables easy positioning of the sample

• The UVIprochemi software includes controls for the motorised zoom lens enabling the user to automatically adjust the aperture, zoom and focus settings from the software screen

• Good Laboratory practice (GLP) function. A GLP file is automatically saved with each image file. The user can input an experiment title, comments and the camera settings. All post-capture image modifications and processing are recorded automatically

• Temperature control indicator helps to ensure that the camera is always at the correct operating temperature




UVIpro Gel Documentation System

Product Specification   Acquisition Software

The UVIpro range is a series of highly sophisticated gel documentation systems for top quality image capture and analysis. Encompassing a comprehensive range of options from the basic and inexpensive UVIpro Bronze to the state of the art UVIpro Platinum, all UVIpro’s are operated from a PC with dedicated software and allow very precise optimisation of the image prior to printing or analysis.

The basic UVIpro design includes a CCD camera (with PCI acquisition card or firewire connection), darkroom cabinet, UV transilluminator, zoom lens, uv/ir filter, and acquisition/basic analysis software package. With choices of camera, darkroom cabinet, zoom lens, filter and UV transilluminator, UVIpro offers the broadest possible range of specifications and price.

• Comprehensive range of models for any application or budget
• Sophisticated image capture and documentation direct to PC
• Highest quality imaging with optional comprehensive analysis
• Ultra-simple, user friendly software interface
• Multi-user capability and Good Laboratory Practice (GLP)

A system for every application and budget!

The UVIpro range includes systems for almost any fluorescence imaging application and budget. Comprising a number of interchangeable modules, there are many choices of UVIpro, from basic, inexpensive models up to the most advanced and sophisticated systems available. For simplicity, the UVIpro range is divided into four main models, Platinum, Gold, Silver and Bronze.

State of the art design

The top of the range UVIpro Platinum incorporates the very best available options throughout. The DBT2000 is the most advanced, efficient and versatile darkroom cabinet available, while the superb quality 14-bit, ultra-high resolution camera is the best available for gel documentation. The motorised zoom lens is easily controlled from the user-friendly software screen and the standard filter offers the highest signal to background ratio available for ethidium bromide detection. These features combine to make UVIpro Platinum the most advanced and sophisticated gel documentation system available.

Easy, intuitive operation

As with the stand-alone UVIdoc system, UVIpro has all the benefits of speed and simplicity. With minimal learning curve and intuitive, icon-driven software, a high quality print out or TIFF file archive can be produced in seconds. UVIpro may be easily used at a number of levels, ranging from simple push button operation to highly precise image optimisation. The live image is viewed on the computer screen and optimised via precise and user-friendly slider bar controls.


CCD Cameras:

UVIpro Bronze, Silver, Gold:

Resolution: 762 x 582
Dynamic range: 8-bit (256 grey levels)

UVIpro Platinum 1.1:

Resolution: 1050 x 1050
Dynamic range: 14-bit (16,384 grey levels)

UVIpro Platinum 2: (available only with manual zoom lens)

Resolution: 1600 x 1200
Dynamic range: 14-bit (16,384 grey levels)


Darkroom cabinets:

DBT-2000: UVIpro Gold & UVIPro Platinum - Advanced ultra-light tight design – Transilluminator (mini-unit) built in and fully enclosed, on convenient pull-out tray – Overhead (epi-) white light as standard and UV light as option – Filter wheel (6 positions, (4 on Platinum 2.0)) – switch-able UV safety door interlock – Lighting options controlled from convenient external switch panel.

DBT-08: UVIpro Silver & UVIPro Platinum -  NEW DESIGN – Compact size, fits onto mini (BXT/BTS) sized transilluminators – UV safety door interlock – overhead (epi-) white light.

HC 40: UVIpro Bronze - Basic camera hood as used with UVIsave system – Lightweight and strong ABS construction – Carrying handle for easy portability – Usable with any transilluminator.


UVIpro product specifications

UVIpro platinum 1.1 & UVIpro platinum 2




UVIpro platinum: designed for the most sophisticated and demanding users who require exceptionally high resolution and dynamic range coupled to the highest level of versatility and automation. UVIpro platinum 1.1 uses a sophisticated 14-bit camera for users who requireextra sensitivity. A choice of manual or motorised zoom lenses are available. UVIpro platinum 2 uses a market leading 14-bit super sensitive camera and high grade manual* zoom lens for exquisite results. UVIpro platinum is available with the versatile DBT-2000 cabinet or the 'classic' DBT-08 cabinet.

Example: GAS75WL-T20:

Includes DBT-2000 cabinet, high resolution, 2.0 megapixel 14-bit firewire camera,

PCI firewire card, manual zoom lens, high performance filter,

BXT-20M transilluminator, UVIpro platinum acquisition software,

Example: GAS7608Z-T20:

Includes DBT-08 cabinet, high resolution, 1.1 megapixel 14-bit firewire camera,

PCI firewire card, motorised zoom lens, high performance filter,

BXT-20M transilluminator, UVIpro platinum acquisition software,

* UVIpro platinum 2.0  is only available with manual zoom lens.



UVIpro Gold



UVIpro Gold: Designed for the user with fewer demands for high resolution and dynamic range but the same requirements for quality and versatility.

Example: GAS74WL-T20:

Includes DBT-2000W cabinet,

SONY 8-bit video camera,

Manual zoom lens and filter,

UVIpro acquisition card and software,

BXT-20M transilluminator,



UVIpro Silver



UVIpro Silver: The original “classic” UVIpro design, ideal for all routine gel documentation applications.

Example: GAS7308Z-T20:

Includes DBT-08 cabinet,

SONY 8-bit video camera,

UVIpro acquisition card and software,

Motorised zoom lens and filter,

BXT-20M transilluminator,

UVIpro bronze



UVIpro bronze: The “economy” model, ideal for small laboratories with limited budget, as a “starter” system, or for laboratories with low usage.

Example: GAS72HC:

Includes HC-40 hood,

SONY 8-bit video camera,

UVIpro acquisition card and software,

Manual zoom lens and filter

UVIpro Acquisition Software

UVIpro acquisition software is designed to maximise flexibility and ease of use, the two most important characteristics for this type of software. Flexibility comes from an array of features for pre-acquisition image optimisation and post-acquisition processing while ease of use comes from the convenient layout and user-friendly adjustment tools. What is more, acquisition parameters can be saved for future use by each individual user and images can be saved in a variety of formats suitable for export to almost any image processing software. The design is in a modern and attractive XP-style, driven by colourful and descriptive icons.

Operating on WINDOWS XP, 2000, 98 and ME platforms, UVIpro includes many features for treatment of a captured image such as brightness, contrast, annotation and basic analysis in a user-friendly and familiar WINDOWS style layout. In addition, UVIpro has the following special features:



• Image Window, providing a full resolution display of live or captured image

• Acquisition toolbar, conveniently including all controls for optimisation of the live image

• Image invert button for viewing an ‘inverted’ live image

• Easy to use slider bars for coarse and fine control of exposure time. Exposure adjustment in two ranges, 80ms-5s in 40ms increments and 5s-120s in 1s increments

• Grid facility for checking alignment of the gel in the field view

• Configuration file saving facility. The acquisition parameters (exposure time, gain, offset) can be saved as a file and re-loaded automatically by opening the file

• Good Laboratory Practice (GLP) function. A GLP file is automatically saved with each image file.

The user can input an experiment title, some comments and the camera lens settings while all post-capture image modifications are recorded automatically. In addition, all relevant software-defined acquisition parameters are saved (eg. exposure time).



Ultraviolet (UV) - Radiometers - UVP

UVX Radiometer This digital UVX Radiometer is used with one of the three interchangeable sensors (ordered separately) for measuring 254nm, 365nm and 302nm UV wavelengths. Measurement of lamp irradiance is the most effective way to monitor the useful life of any UV light source.  Main Features  •  Order from three sensors: UVX-25 shortwave, UVX-31 midrange or UVX-36 longwave  •  The chart recorder port, standard on the UVX, allows for continuous monitoring  •  The UVX's range switch provides selection from three intensity ranges:    0 to 20 mW/cm2, 0 to 2000 microW/cm2 and 0 to 200 microW/cm2  •  The 10:1 attenuator extends the reading range up to 200mW/cm2  •  The UVX Radiometer is powered by a 9-volt battery for up to 120 hours  •  Unit includes a port for attachment of a chart recorder (user provided)  Options All meters and sensors are individually serialized for traceability of calibration. Calibration is recommended every six months and is certified to meet UVP's published standards and is traceable to NIST. Calibrations are performed at UVP's factory.    Technical Information Model UVX Conversion Rate: 2.8 readings/second Display: 3.5 digit LCD Accuracy: +/-2% Sensors Accuracy: +/-5% (includes NIST standard) Dimensions 157 x 51 x 91 mm Weight: 0.3 kg

UVImap 1D Analysis Software



Effortless, trouble free comparative analysis

 • Password protected database for easy storage & retrieval of molecular weight data

• Database search facility for lane homologies

• Inter gel comparison using matrix & dendogram analysis

• Multiprobe analysis for RFLP/RAPD

Applications include:

Pattern recognition, DNA  mapping, RFLP and RAPD analysis



UVIlite Ultraviolet Lamps



A very wide range of ultraviolet lamps from low power hand held models to high intensity units is available. There are filtered lamps in three wavelengths for use in fluorescent techniques and unfiltered lamps in both long and short (germicidal) wavelengths. All incorporate an extruded, anodised aluminium housing and a specially designed unique profile has been developed for the hand held lamps. The operator friendly shape permits lamps to be held easily with gloved hands.

Filtered lamps

These highly efficient, well designed lamps are produced in three wavelengths: 254, 312 and 365nm and dual wavelength combinations. Power ranges from a single 4W tube up to two 15W tubes.

Applications include:

Short wavelength (254nm)

Fluorescence techniques, fluorochemistry, mineralogy, photopolymerisation, mutation studies, toxicology.

Mid wavelength (312nm)

Electrophoresis gel viewing.

Long wavelength (365nm)

TLC plate viewing, fluorochemistry, food inspection, quality control, titration, pesticide analysis, mineralogy

Ordering UVIlite filtered UV lamps

LF 104S	50 x 75	1 x 4W	254	340
LF 204LS	50 x 75	1 x 4W	365	350
		1 x 4W	254	265
LF 106L	50 x 150	1 x 6W	365	700
LF 106S	50 x 150	1 x 6W	254	710
LF 106M	50 x 150	1 x 6W	312	680
LF 206LM	50 x 150	1 x 6W	312	580
		1 x 6W	365	610
LF 206MS	50 x 150	1 x 6W	312	580
		1 x 6W	254	400
LF 206LS	50 x 150	1 x 6W	365	610
		1 x 6W	254	400
LF 215L	80 x 300	2 x 15W	365	2300
LF 215S	80 x 300	2 x 15W	254	1780
LF 215M	80 x 300	2 x 15W	312	2200
LF 215LM	80 x 300	1 x 15W	365	1350
		1 x 15W	312	1330
LF 215MS	80 x 300	1 x 15W	312	1330
		1 x 15W	254	930
LF 215LS	80 x 300	1 x 15W	365	1350
		1 x 15W	254	930

Intensity at 15cm µW/cm2

High intensity lamps

Incorporating cold cathode quartz grid lamps, housed in anodised aluminium extrusion and with the same highly efficient ondulex reflector as filtered lamps. The power supply unit is remote from the lamp head in a separate metal package. Grid lamps produce high intensity, very consistent, short-wavelength (254nm) ultraviolet illumination. The 100W units are available fitted with longlife filters or to special order without filter for germicidal applications.

Applications include:

Biotechnology – mutagenesis, photopolymerisation, toxicology, mycology, sterilisation.

Ordering high intensity lamps

Model No.	Filter (mm)	Wavelength (nm)	Intensity
LF 180S	70 x 300	254	3400





Unfiltered ultraviolet lamps

Germicidal lamps

Widely used in medical and scientific research laboratories as well as in electronics and the food and beverage industries. Areas that must be kept free from bacterial contamination may be irradiated with UVItec germicidal lamps, provided safeguards are in place to protect operators. The same range of lamps is available with either BL or BLB long-wavelength tubes:

BL (Blacklight) tubes are actinic ultraviolet type and include a white light component in the output.

Applications for BL lamps include:

Polymer curing, adhesive curing, dermatology, pharmacology, photoresist exposure.

BLB (Blacklight Blue) tubes are self-filtered cobalt glass – to reduce the visible light component and increase fluorescent contrast.

Applications for BLB lamps include:

Non-destructive testing, quality control, invisible coding/marking, counterfeit note detection, rodent contamination detection, readmission control, aflatoxin detection, signature verification.



UVIlite Unfiltered UV germicidal lamps 254nm

Model Number	Tubes	Intensity µW/cm2
LI 206G	2 x 6W	1400 *
LI 208G	2 x 8W	1800 *
LI 215G	2 x 15W	76
LI 315G	3 x 15W	95
LI 220G	2 x 20W	95
LI 320G	3 x 20W	119
LI 230G	2 x 30W	152
LI 330G	3 x 30W	191
LI 240G	2 x 40W	157
LI 340G	3 x 40W	219

Intensities all at 1m except* at 15cm

UVIlite Unfiltered UV longwave lamps 365nm



Model Number	Tubes	Intensity µW/cm2
LI 206BL	2 x 6W BL	1215 *
LI 208BL	2 x 8W BL	1400 *
LI 215BL	2 x 15W BL	108
LI 315BL	3 x 15W BL	147
LI 220BL	2 x 20W BL	129
LI 320BL	3 x 20W BL	177
LI 230BL	2 x 30W BL	228
LI 330BL	3 x 30W BL	312
LI 240BL	2 x 40W BL	302
LI 340BL	3 x 40W BL	413
LI 206BLB	2 x 6W BLB	1120 *
LI 208BLB	2 x 8W BLB	1300 *
LI 215BLB	2 x 15W BLB	100
LI 315BLB	3 x 15W BLB	136
LI 220BLB	2 x 20W BLB	119
LI 320BLB	3 x 20W BLB	163
LI 230BLB	2 x 30W BLB	210
LI 330BLB	3 x 30W BLB	288
LI 240BLB	2 x 40W BLB	279
LI 340BLB	3 x 40W BLB	381

Intensities all at 1m except* at 15cm



Germicidal radiation required for bacterial destruction



Bacteria	Energy in mW-sec/cm2   Sterilisation up to 90%	Energy in mW-sec/cm2   Sterilisation up to 99%
Bacillus anthracis	4.52	9.04
S. enteritidis	4.00	8.00
B. megatherium sp.(veg.)	1.30	2.60
B. megatherium sp.(spores)	2.73	5.46
B.paratyphosus	3.20	6.40
B.subtilis	7.10	14.20
B. subtilis spores	12.00	24.00
Corynebacterium diphtheriae	3.37	6.74
Eberthella typhosa	2.14	4.28
Escherichia coli	3.00	6.00
Micrococcus candidus	6.05	12.10
Micrococcus sphaeroides	10.00	20.00
Neisseria catarrhalis	4.40	8.80
Phytomonas tumefaciens.	4.40	8.80
Proteus vulgaris	2.64	5.28
Pseudomonas aeruginosa	5.50	11.00
Pseudomonas fluorescens	3.50	7.00
S. typhimurium	8.00	16.00
Sarcina Lutea	19.70	39.40
Seratia marcescens	2.42	4.84
Dysentery bacilli	2.20	4.40
Shigella paradysenteriae	1.68	3.36
Spirillum rubrum	4.40	8.80
Staphylococcus albus	1.84	3.68
Staphylococcus aureus	2.60	5.20
Streptococcus hemolyticus	2.16	4.32
Streptococcus lactis	6.15	12.30
Streptocuccus viridans	2.00	4.00

DISCLAIMER: THE ABOVE TABLE IS ONLY A GUIDELINE FROM WOLF/UVItec FOR THE DESTRUCTION OF BACTERIA.

WOLF/UVItec CANNOT BE HELD RESPONSIBLE FOR ANY ERRORS FOUND IN THE TABLE.

UVIlink Ultraviolet Crosslinker



• Programmable microprocessor control

• UV energy monitored automatically

• Compact footprint with large interior

• Observation window – UV blocking

• Membrane keypad operation

• Clear LED display

• Safety interlocked

Simple yet versatile

The UVIlink CL 508 Crosslinker is a fully microprocessor controlled unit especially designed to give the best possible results when binding nucleic acids to membranes. The correct ultraviolet dosage can be set using the membrane switch keypad, in either energy units (Joules) or time (seconds). There are nine possible presets for energy exposure and nine presets for time exposure as well as manual user selection in either units.

Superb quality results in less time

Ultraviolet crosslinking of DNA and RNA to nylon or nitrocellulose membranes is now well established as a laboratory technique and there is considerable published work on the topic. Time saved from UV crosslinking over the conventional vacuum oven baking method is considerable – seconds or minutes as opposed to hours.

Small and safe without compromising efficiency

UVIlink CL 508 provides a compact unit occupying minimum bench space with a footprint of only 350 x 350 mm and a spacious interior chamber of 270 x 300 x 140 mm. As with all UVItec products, safety is a major consideration so the CL508 door is safety interlocked against opening during operation and the observation window in the door is ultraviolet blocking.

The ultraviolet energy is continuously monitored by an accurate microprocessor controlled photo feedback system which compensates for variation in output from the UV sources. In this way consistency of operation and maximum efficiency are maintained.

Applications include:

• Fixing of nucleic acids to nylon or nitrocellulose membranes

• Southern or Northern blotting, dot blotting and colony or ple lifts

• Elimination or reduction of PCR contamination

• Nicking ethidium bromide stained DNA in agarose gels

• Gene mapping for creating cleavage inhibiting thymine dimers

• Screening RecA mutation

• Ultraviolet curing of polymers, adhesives and inks

• Ultraviolet sterilisation

Technical characteristics

Dimensions- Exterior	350 x 350 x 300mm
Dimensions Interior	300 x 270 x 140mm
Weight	10.5kg
Ultraviolet wavelength	254, 312 or 365nm
Tubes	5 x 8Watt tubes
Controls	9 preset ultraviolet energy levels
	9 preset exposure times
	manual UV energy level setting
	manual exposure setting
maximum ultraviolet energy levels
Two ranges:	from 0 to 9.999 Joules
	from 0 to 99.99 Joules
maximum ultraviolet time exposure	999.9 minutes

-Internal safety interlock
-large LED readout
-membrane switch keypad
-UV blocking observation window
-conveniently small footprint
-Large interior UV exposure chamber
-Dual safety fused
-Removable electrical mains lead
-Electrical nominal
-Voltage/Hertz:	115V/60Hz
	230V/50Hz
	100V/50-60Hz





UVIdoc Gel Documentation System



UVIdoc is a superbly designed low cost documentation system featuring a unique combination of simplicity and versatility

It operates as a stand-alone system for producing high quality thermal prints of gel images. However, the compact flash slot also allows image capture direct to a flash card  (as TIFF or JPG files). The images produced can be saved as a suberb 12 bit file, the format can be chosen by the user. The images can then be loaded into the UVIgeltec software which enables image manipulation, annotation and simple analysis. Saturation monitoring of the live image ensures that fully quantifiable images may be captured first time.



• Ultra-simple, low cost documentation systems
• 12 bit file format for increased dynamic range
• GAS9500 now with 5.6 inch TFT screen
• Ideal for multi-user environments
• Compact flash for saving images as TIFF or JPG file formats
• Light saturation of image detectable on monitor or LCD screen
• Fully networkable allowing easy image transfer to and from a PC.

A brand new unique feature for the UVIdoc is the addition of a network card into the darkroom cabinet. This will enable the user to install the UVIdoc onto their local network allowing fast and easy access to images already stored on the UVIdoc. Random Access memory (RAM) will allow 30 images to be stored for easy transfer.

UVIdoc is available in two versions. GAS9500 has a built-in 5.6 inch LCD screen which replaces the CCTV monitor supplied with GAS9000. All other features and functions are the same for both systems.

Because both models of UVIdoc are so simple to operate, minimal training is required and high quality images can be acquired in seconds. This, combined with safety features, makes either UVIdoc ideal for environments with a high number of regular or casual users. The user interface includes a wipe-clean six-button key-pad conveniently positioned at eye level. A safety-interlocking darkroom door protects the user from harmful UV output.

No more queues for documentation

Many laboratories have already discovered the benefits of UVIdoc speed and simplicity. With no learning curve and only a few buttons to press, a high quality print out or image file on flash or floppy can be produced in seconds, making darkroom queues a thing of the past. For the more advanced user, images can be transferred from the UVIdoc by a local network connection.

Multi-user UVIdoc

UVIdoc is currently in use in many research departments as a central facility for large numbers of users. The safety, speed and robustness of UVIdoc have even made it an essential tool in many teaching laboratories, the ultimate multi-user environment!

Multi-purpose UVIdoc

UVIdoc’s special combination of simplicity and functionality has made it indispensable to a wide range of users. The saturation monitoring function means that UVIdoc can be used by researchers who wish to quantify their gel images and also ensures no loss of detail from the image due to saturation. The system can therefore be used on a variety of levels, from simple hard copy generation, to more sophisticated image acquisition for analysis.

UVIdoc – dedicated to simplicity

The unique design of UVIdoc incorporates a user interface which is simplicity itself. Exposure time is varied by pressing a ‘+’ button to increase and a ‘–’ button to decrease. The exposure time is in 17 pre-set steps, ranging from 40ms up to 10secs. Just four other buttons control features such as live/freeze modes, saturation monitoring, save to flash or disk and read from flash or disk. All functions are accessed by a single button push.

Standard components include

• Darkroom and Control Unit
• BXT-20M Mid range (312nm) dual intensity Transilluminator
• SONY CCD Camera
• Zoom lens and filter
• UVIdoc software


Optional Extras

• Mitsubishi P93 Thermal Printer
• UV to white light conversion screen with 26 x 21cm active area (optional extra)

UVIchrompro tlc Documentation System

UVIchrom-pro is an inexpensive system, specially designed for PC-based documentation and analysis of thin layer chromatography (TLC) plates. It is similar to the UVIpro system (see p4), but has a different darkroom cabinet and UV light source, plus a slightly modified software package in which the Molecular weight analysis function is replaced by Rf value calculation.

The UVIchrom darkroom hood is designed for efficient overhead UV illumination and imaging of thin layer chromatography plates. It incorporates four powerful (15 watt) UV tubes of optional wavelengths, positioned two on each side, above and close to the sample for maximum efficiency and uniformity of illumination. The camera is fixed to a special central mounting unit. White light illumination to aid sample positioning is also incorporated into the hood. The cabinet will allow imaging of plates in excess of 20 x 20cm.

UVIchrom can also be used with a high quality (3 CCD chip) colour camera and a dye sublimation printer. These can be supplied (at additional cost) in place of the standard 8-bit monochrome CCD camera and b+w thermal printer.





• Simple, low cost system specially designed for TLC plate documentation



• Specially designed darkroom cabinet for efficient and powerful overhead illumination of TLC plates

• Specially adapted UVIpro software allows basic image analysis with Rf value calculation for TLC spots

• Optional 3 CCD Colour Camera plus Dye Sublimation printer for exceptional results

In addition to the standard, PC-based UVIchrom-pro system (PAS-5000), there is also a stand-alone (UVIdoc-type) system, the UVIchrom-doc (PAS-4000). This has the same darkroom cabinet, camera and printer as the UVIchrom-pro, but the PC acquisition card and software are replaced by a stand-alone control unit offering the same features and functions as the UVIdoc system. UVIchrom-doc is not available with the colour camera and printer option.



UVIchemi Chemiluminescence Imaging System

Acquisition Software

super cooled for unrivalled sensitivity, unbeatable performance

UVIchemi is a state of the art dedicated chemiluminescence imaging system, designed for users who demand the very highest sensitivity and performance. The superb scientific grade CCD camera, with REAL 12-bit dynamic range, mega-pixel resolution and exceptionally low noise means that the UVIchemi can detect samples when other high specification imaging systems cannot. Long exposures without loss of image quality are made possible by the unique two-tier cooling system that keeps background noise to a minimum. The top quality fixed focal length lens ensures razor sharp image resolution at all times. The UVIchemi darkroom cabinet has a sample tray with 6 vertical positions and is precision made with a special door locking mechanism to eliminate light leakage.

• Dedicated chemiluminescence system

• Unrivalled sensitivity for chemiluminescence applications

• Scientific grade, high-performance CCD camera

• Automatic exposure control

• Ultra light-tight compact darkroom

The UVIchemi system from UVItec has been developed exclusively for users who require a dedicated chemiluminescence documentation system. Unlike most systems that have been designed primarily for fluorescence documentation and adapted for chemiluminescence, the UVIchemi system has been created around the specific needs of chemiluminescence documentation and analysis.

While some of our competitors who claim to use TRUE "16 bit" output from cameras with inferior performance, we at UVItec prefer to use a the top of the range 12 bit camera with real 12-bit performance, meaning ultra low noise and exquisite sensitivity.


UVIchemi components:

The UVIchemi system consists of a light tight darkroom with a sample tray that has six different positions. Samples of up to a maximum size of 22cm by 18cm can be accommodated on the sample tray.

• CCD chip cooled to -45°C below ambient
• Fully enclosed camera housing  with its own unique  additional cooling system (improves camera efficiency in laboratories with high ambient temperatures)
• Class leading high sensitivity, 12 bit digital camera with 3-stage peltier cooling
• Overhead LED lighting for easy positioning of the sample
• Image acquisition using UVIchemi software via FireWire interface
• Optional digital thermal printer for superior quality prints
• Optional UVIband analysis software allows for accurate quantification of samples and much more



UVIchemi Performance


The UVIchemi system provides users with exceptional high end performance using all major types of Chemiluminescent substrates including ECL, ECL-PLUS, CSPD,  CDP & CDP-STAR. The high sensitivity CCD camera permits exposure times from 0.1 seconds up to 120 minutes.

The UVIchemi system outperforms its nearest competitors in two ways:

1. The greater camera sensitivity results in greatly reduced exposure times

2. The extremely low noise level enables very long exposure times when necessary without the loss of image quality



Acquisition Software

UVIsoft for UVIchemi & UVIprochemi

The UVIchemi and UVIprochemi acquisition software facilitates simple and rapid optimisation of images when long exposures are necessary. Automatic exposure mode makes it possible to acquire fully optimised images of the very faintest samples at the push of a button. Varying levels of user control over the image acquisition process are offered by the semi-automatic and manual exposure modes. Acquisition parameters can be saved in configuration files for future use and are automatically saved with each image in a secure GLP file. The attractive software interface features large colour coded buttons and self-evident icon designs to minimise the user learning curve. The UVIprochemi software also includes zoom lens controls and a saturation monitor function.



• Easy to use with Windows® XP style software interface
• Automatic exposure control
• Video mode for sequential capture
• Save individual user settings
• Image saturation monitor
• GLP file automatically saved with each image



More Software Details

• Automatic Exposure mode automatically calculates the exposure time so that the image can be captured in one simple "click".
• Manual Exposure mode allows the user the set their own exposure time. From 1/10th of a second up to 120 min
• Test Function detects when the signal produced by the Chemiluminescent reaction is intense enough for an exposure to be made.

• Video mode enables the user to monitor the progress of a Chemiluminescent reaction by taking a series of exposures at user defined intervals

• Annotation function allows text as well as the date and time to be added to the image

• Positive/Negative button allows viewing an ‘inverted’ image

• Live mode enables easy positioning of the sample

• The UVIprochemi software includes controls for the motorised zoom lens enabling the user to automatically adjust the aperture, zoom and focus settings from the software screen

• Good Laboratory practice (GLP) function. A GLP file is automatically saved with each image file. The user can input an experiment title, comments and the camera settings. All post-capture image modifications and processing are recorded automatically

• Temperature control indicator helps to ensure that the camera is always at the correct operating temperature



UVIcab Ultraviolet Viewing Cabinets



CV 415 cabinet

Professional unit for effective viewing with power intensity unequalled in this field.

Features

• Incorporates 4 x 15Watt UV tubes plus one 40Watt white light bulb

• Any single or dual wavelength combination of 254, 312 and 365nm wavelengths

• Easy control switch operation for each wavelength

• Versatile: simply change the tubes when a new wavelength is required

• Removable base panel enabling positioning above a standard transilluminator

• Viewing port with UV absorbing filter

 Applications of CV cabinets

• Reading chromatograms (paper or TLC)

• Fluorescent analysis in Biology, Chemistry and Forensics

• Industrial and electronic quality control

• Can also be used for applications in Geology and Mineralogy

 CV006 cabinet

An economic solution to laboratory inspection of fluorescent samples.

 Features

• Compact, lightweight, versatile and efficient

• Can hold one or two UVIlite, 6W UV lamps

• Choose from 254, 312 or 365nm wavelength

• Strong, lightweight design with black curtain

• Viewing port with UV absorbing filter



UVIbandmap 1D Analysis Software

The complete all inclusive 1D package

 • All the benefits of UVIband and UVImap at your fingertips

• 70+ functions

• The only 1D analysis software you will ever need



All UVIsoft software comes as standard on CD-ROM with comprehensive user manual

UVIband 1D Analysis Software

Versatile and powerful quantitative analysis



•  Precise, accurate band quantification

•  Fully automated background subtraction

•  Calculates actual 3D volume, not 2D band area

•  Relative or absolute band quantities calculable from reference bands or lane

Applications Include:

PCR, RT-PCR, competitive PCR, protein expression, molecular weight/Rf analysis, dot blot/microtitre analysis.





UVP UV to White Light Converter Plates

		UV to white light converter plates.  A specially designed plate converts a transilluminator's ultraviolet radiation to white light for viewing protein gels, coomassie blue stained or silver stained media.
Key Features: A specially designed plate converts a transilluminator's ultraviolet radiation to white light for viewing protein gels, coomassie blue stained or silver stained media. The Converter Plate's uniquely phosphored glass assembly (patent pending) converts the UV radiation via a white diffuser. The scratch-resistant glass is mounted in a metal housing for durability. Handles are situated on two sides of the plate for easy handling. Two plates are available for covering transilluminator filter surface sizes up to 21 x 26cm or 20 x 40cm. Custom sizes are also available.    PCR Cabinets - UVP     UV PCR Equipment brings together UV irradiation and antimicrobial stainless steel to create a dual-attack environment against PCR contamination. Choose from cabinet or workstation. The cabinet features a smaller work area than the workstation.  Applications • PCR Preparation and Amplification • Microbial research Main Features • Control potential PCR contamination with the built-in UV for inactivation of DNA between experiments  • The 254nm shortwave UV source positioned as overhead UV; select models include UV air recirculator to circulate the UV sterilized air  • UV is controlled with a key switch and 30-minute timer to decontaminate apparatus and chamber with the shortwave UV  • The shortwave ultraviolet irradiation can be used as a standard laboratory practice to reduce surface and airborne contaminants in the chamber  • A safety shut-off switch automatically turns the ultraviolet light off when the door is open  • Antimicrobial coated stainless steel reduces bacterial growth  • The workstation is designed for placement of large instruments on the work area or tubes, flasks and pipettes on the two removable shelves  • The built-in power outlets allow operation of equipment for use in PCR applications. Technical Information UV Sterilizing PCR Cabinet* Exterior Dimensions: 28.7H x 21.4W x 24D in. (729 x 544 x 610 mm) Interior Dimensions: 19.7W x 21.4D in. (500 x 544 mm)  Light Sources: 254nm 8-watt UV: Chamber  White - 8-watt: Chamber Features include: • Two power outlets  • Two small shelves  • UV Timer  • Antimicrobial coated stainless steel  • Acrylic panels block below 400nm UV2 Sterilizing PCR Cabinet* Exterior Dimensions: 28.7H x 21.4W x 24D in. (729 x 544 x 610 mm) Interior Dimensions: 19.7W x 21.4D in. (500 x 544 mm)  Light Sources: 254nm 8-watt UV: Chamber / UV/Air Recirculator  White - 8-watt: Chamber Features include: • Two power outlets  • Two small shelves  • UV Timer  • Antimicrobial coated stainless steel  • Acrylic panels block below 400nm UV Sterilizing PCR Workstation* Exterior Dimensions: 28.7H x 29W x 24D in. (729 x 737 x 610 mm) Interior Dimensions: 27.8W x 21.4D in. (706 x 544 mm)  Light Sources: 254nm 25-watt UV: Chamber  White - 15-watt: Chamber Features include: • Four power outlets  • Two small shelves  • UV Timer  • Antimicrobial coated stainless steel  • Acrylic panels block below 400nm UV2 Sterilizing PCR Workstation* Exterior Dimensions: 28.7H x 29W x 24D in. (729 x 737 x 610 mm) Interior Dimensions: 27.8W x 21.4D in. (706 x 544 mm)  Light Sources: 254nm 25-watt UV: Chamber / Air Recirulator  White - 15-watt: Chamber Features include: • Four power outlets  • Two small shelves  • UV Timer  • Antimicrobial coated stainless steel  • Acrylic panels block below 400nm * Assembly Required



PCR Cabinets - UVP

Multi-featured equipment for eliminating PCR contamination! PCR equipment brings together UV irradiation and antimicrobial stainless steel to create a dual-attack environment against PCR contamination. HEPA/UV PCR models feature a four-stage filter assembly plus UV to eliminate contamination. Two sizes are available: cabinet and workstation. Applications • PCR Preparation and Amplification • Microbial research Main Features Filtered and sterilized air treated by the UV/HEPA system flows into the PCR chamber. Control potential PCR contamination with built-in UV for inactivation of DNA between experiments. Shortwave UV can be used as a standard laboratory practice to reduce surface and airborne contaminants in the chamber. • Four stage filter system:     -Pre-filter captures large dust particles     -Carbon filter (activated charcoal) eliminates gases, odor, smoke and also reduces ozone to improve microarray data quality     -HEPA (high efficiency energy particulate) filter blocks particles down to 0.3 microns     -ZerOzone catalyst grid not only blocks ozone but it also supplies a gentle airflow onto the sample work area. This airflow creates a working environment that blocks entry of unwanted contaminants on PCR samples. • Three UV (UV3) sources:     -Filter area     -Chamber work area     -UV/air recirculator • A 30-minute timer sets shortwave UV exposure to decontaminate apparatus and work chamber for specific times  • Antimicrobial coated stainless steel reduces bacterial growth  • A safety shut-off switch automatically turns the ultraviolet light off when the door is open  • Place large instruments on the work area or tubes, flasks and pipettes on the two removable shelves  • Built-in power outlets allow operation of equipment for use in PCR applications  • Acrylic panels are specially formulated to block UV wavelengths below 400nm Technical Information UV3 HEPA PCR Cabinet* Exterior Dimensions: 32.5H x 21.4W x 24D in. (826 x 544 x 610 mm) Interior Dimensions: 19.7W x 21.4D in. (500 x 544 mm)  Light Sources: 254nm UV: • Filter area  • Chamber  • UV/air recirculator White: Chamber Four stage filters: • Pre-filter  • Carbon filter  • HEPA filter  • ZerOzone catalyst grid Features include: • Three UV sources  • Four stage filters  • Two power outlets  • Two small shelves  • UV Timer (< 30 min.)  • Antimicrobial coated stainless steel • Acrylic panels block below 400nmm UV3 HEPA PCR Workstation* Exterior Dimensions: 32.5H x 29W x 24D in. (826 x 737 x 610 mm) Interior Dimensions: 27.8W x 21.4D in. (706 x 544 mm)  Light Sources: UV: • Filter area  • Chamber  • UV/air recirculator White: Chambermber Four stage filters: • Pre-filter  • Carbon filter  • HEPA filter  • ZerOzone catalyst grid Features include:   • Three UV sources  • Four stage filters  • Four power outlets  • Two shelves  • UV Timer (< 30 min.)  • Antimicrobial coated stainless steel  • Acrylic panels block below 400nm * Assembly Required

Ultraviolet (UV) - Lamps - UVP

Compact UV Lamps PL Series lamps includes the lightweight, compact UV Lamps (4 watt lamps) which fit comfortably in the hand. This lamp is available in 115V, 230V and 12VDC versions. Main Features •  Models available include 254nm shortwave, 365nm longwave or a combination shortwave/longwave version  •  Shortwave/longwave version comes with a snap-on wavelength selector for switching between wavelengths  •  Lightweight, easy-to-handle lamp design  •  4 watts  Specifications  Housing: Plastic  UV: Select from models with 254nm or 365nm UV or combination of both wavelengths  Dimensions: Compact Lamps: 7.8L x 2.8W x 2.1D in. ()  Options  •  Use Compact UV Lamps with J-124 Lamp Stand for hands free operation •  Use the lamps with C-10 Chromato-Vue Viewing Cabinet for viewing materials in a darkened environment •  The Compact UV Lamp is available in a 12 Volt style (for cigarette lighter operation) which is designed for windshield curing (lamp part number 95-0019-14) •  UV blocking eyewear Technical Information Model UVL-23R UVL-21 UVGL-15 UVG-11 UVGL-25 Wavelength 365nm 365nm 254nm and 365nm 254nm 254nm and 365nm Watts 4 Dimensions 135 x 75 x 18mm

UVIlink

Ultraviolet Crosslinker CL 508

Programmable microprocessor control

UV energy monitored automatically
Compact footprint with large interior
Observation window - UV blocking
Membrane keypad operation
Clear LED display
Safety interlocked

Applications include:

Fixing of nucleic acids to nylon or nitrocelulose membranes, Southern or Northern blot or dot blotting and colony or plaque lifts. Elimination or reduction of PCR contamination. Nicking ethidium bromide stained DNA in agerose gels. Gene mapping for creating cleavage inhibiting thymene dimers. Screening RecA mutation. Ultraviolet curing of polymers, adhesives and inks. Ultraviolet sterilisation.

The UVIlink CL 508 Crosslinker is a fully microprocessor controlled unit especially designed for the best possible results binding nucleic acids to membranes. The correct ultraviolet dosage can be set using the membrane switch keypad, in either energy units (Joules) or time (seconds). There are nine possible presets for energy exposure and nine presets for time exposure as well as operator selection manual control in either units

Ultraviolet crosslinking of DNA and RNA to nylon or nitrocelulose membranes is now well established as a laboratory technique and there is considerable published work on the topic -UVItec can provide a list of references. Time saving from UV crosslinking over the conventional vacuum oven baking method is considerable -seconds or minutes as opposed to hours. Now the UVIlink CL 508 provides a compact unit occupying minimum bench space with a footprint of only 350 x 350mm and a spacious usable interior chamber of 270 x 300mm. As with all UVItec products safety is a major consideration and so the CL 508 door is safety interlocked against opening during operation and the observation window in the door is ultraviolet blocking. The ultraviolet energy is continuously monitored by a microprocessor controlled photo feedback system which compensates for variation in output from the UV sources, particularly tube ageing. In this way consistency of operation and maximum efficiency is maintained

Technical characteristics

Dimensions- Exterior	350 x 350 x 300mm (w x d x h)
Dimensions- Interior	300 x 270 x 140mm (w x d x h)
Weight	10.5kg
Ultraviolet wavelength	254, 312 or 365nm
Tubes	5 x 8Watt tubes
Controls	9 preset ultraviolet energy levels
	9 preset exposure times
	manual ultraviolet energy level setting
	manual exposure time setting
maximum ultraviolet energy levels
Two ranges:	from 0 to 9.999 Joules
	from 0 to 99.99 Joules
maximum ultraviolet time exposure	999.9 minutes

-Internal safety interlock
-large LED readout
-membrane switch keypad
-UV blocking observation window
-conveniently small footprint
-Large interior UV exposure chamber
-Dual safety fused
-Removable electrical mains lead
-Electrical nominal
-Voltage/Hertz:	115V/60Hz
	230V/50Hz
	100V/50-60Hz





Transilluminators - UVP

Visi-Blue™ Transilluminators Visi-Blue Transilluminators are UV safe and convert 365nm UV to 460-470nm blue light for use with various stains including GFP stains, SYBR Green and SYPRO Orange. Two filter sizes are available.  Main Features  Visi-Blue Transilluminators are designed for use with GFP stains. As compared to UV, the blue light will transmit through almost any transparent (plastic, glass, etc.) laboratory equipment. This is essential when monitoring and detecting DNA migration and protein expression in real time.  •  Two models are available with surface areas as follows: 21x26cm or 20x40cm  •  Select from models with 8-watts or 25-watts  •  Amber cover (included) blocks blue light transmission and allows visualization of media above 500nm Specifications  Intensity: Select models offer single intensity other models include variable intensity. Refer to the part numbers tab for information. Variable intensity settings: High/Medium/Low - High setting allows for UV excitation of fluorophores on gels for routine photography. Medium is excellent for viewing and quick single-band excision. Low setting allows for positioning and preparation of gels, excising multiple bands, and focusing for photography. Light Source: 460-470nm  VB-26 Watts: 8 watts  VB-40 Watts: 25 watts  Options  •  Gel Tools Technical Informationn Model VB-26V VB-40V Type Visi-Blue Intensity Style Variable Wavelength 460-470nm Filter Size 210x260mm 200x240mm Dimensions (DxWxH) 241 x 337 x 121mm 337 x 486 x 143mm *Height includes UV blocking orange cover

Transilluminators - UVP

Benchtop UV Transilluminators UVP offers a wide range of filter sizes and single or multiple UV wavelength transilluminators in a compact, benchtop size. UVP's patented 3UV™ Benchtop Transilluminator (main picture) provides the selection of longwave, midrange and shortwave in one compact unit. Main Features  New electronic ballast and cutting-edge construction offers:  •  Increased ultraviolet output and intensity  •  No light flicker  •  Wider intensity range with variable selection (select models)  •  Fast lamp start up  •  Universal power supply  •  Reduced electrical consumption  •  Longer tube life  •  Lighter weight  •  Improved gel visualization and gel documentation •  UVP's patented 3UV Benchtop Transilluminator provides the selection of 365nm, 302nm and 254nm in one compact unit  •  2UV models offer 302nm and 365nm UV in one model  •  Easily view gels under 365nm longwave UV for extended periods of time avoiding photonicking damage. Researchers can use the 302nm midrange to increase the fluorescence for photodocumentation. Shortwave 254nm UV is used to irradiate samples  •  All Benchtop Transilluminator models are compact, lightweight units  •  These 8-watt models provide a low cost alternative to the High Performance UV Transilluminators  •  A variety of filter area work surface sizes are available  •  Hinged, clear UV blocking cover, included with each transilluminator, is adjustable for access to the filter surface WARNING: Transilluminators are powerful sources of ultraviolet radiation which can cause serious damage to unprotected eyes and skin.   Specifications  Intensity: Select models offer single intensity other models include variable intensity. Refer to the part numbers tab for information.  Variable intensity settings - High/Medium/Low: High setting allows for UV excitation of fluorophores on gels for routine photography. Medium is excellent for viewing and quick single-band excision. Low setting allows for positioning and preparation of gels, excising multiple bands, and focusing for photography. UV Source: Refer to the Part Numbers tab for specific wavelengths for each model  Watts: 8 or 6 - Refer to the Part Numbers tab for watts Options  • Gel Tools  • Converter Plates  • BioImaging Systems • UV Blocking Eyewear Technical Informationn Model M-20V M-26V M-26XV LM-20 LM-26 Type Single UV 2UV Intensity Style Variable Single Wavelength 302nm 365/302nm Watt 8 Filter Size 200x200mm 210x260mm 250x260mm 200x200mm 210x260mm Dimensions (DxWxH) 279 x 356 x 122mm 279 x 356 x 122mm

UVP Transilluminator Converter Plates



Maximize transilluminator capabilities by using a converter plate to convert the transilluminator's 302nm UV wavelength to different wavelengths for visualizing a variety of gels. Place the specially designed plate on the transilluminator filter surface. Photo shows 21x26cm Visi-Blue Plate and 20x40cm White Light Plate.

Applications

• Variety of wavelengths for Gel Documentation

Features

Several specially designed converter plates convert a transilluminator's 302nm ultraviolet radiation .

• To white light for viewing protein gels, coomassie blue stained or silver stained media. The Converter Plate's uniquely phosphored glass assembly (patent pending) converts the UV radiation via a white diffuser
• Convert UV:
  • To 460-470nm with the Visi-BlueT plate for viewing GFP stains
  • To 365nm UV with the UV/UV plate for preparation and gel excision
• The scratch-resistant glass is mounted in a metal housing for durability
• Rubber seal stops the plate from sliding
• Handles are situated on two sides of the plate for easy handling
• Several standard plate sizes are available; custom sizes are also available



Part Numbers
Part Number	Model	Filter
38-0191-01	UV to White Light Converter Plates	21x26cm
38-0191-02	UV to White Light Converter Plates	20x40cm
38-0191-04	UV to White Light Converter Plates	25x26cm
38-0200-01	Visi-Blue Converter Plates	21x26cm
38-0200-02	Visi-Blue Converter Plates	20x40cm
38-0200-04	Visi-Blue Converter Plates	25x26cm
38-0325-01	UV to UV Converter Plate	25x26cm

UVP Digital Thermal Printer

Document gels, films and membranes with a high quality thermal printer. Easily connects for use with UVP’s imaging systems (except PhotoDoc-It). Process low cost prints in seconds. Replacement paper rolls install easily.   Technical Information Dimensions:(H x L x W) 273 x 330 x76mm

UVP Rechargeable/Portable Ultraviolet Lamps

UVSL-26P Rechargeable UV Lamp		Carry the portable/rechargeable 6 watt UV lamps anywhere! Built-in lead acid battery allows hours of use! Select from longwave or shortwave UV models or a combination of wavelengths in one lamp.
Key Features: Rechargeable lamps are equipped with an internal gel-based, lead-acid battery which can be charged for field operation from a standard wall outlet A 12V adapter is available for operating the lamp from a car cigarette lighter Rechargeable Lamps have two tubes for added UV intensity Model UVSL-26P shown can operate with both longwave and shortwave on at the same time The C-10P Viewing Cabinet (optional) securely holds a Rechargeable UV Lamp, providing a convenient portable darkroom Rechargeable Lamp Dimensions: 5.5"L x 3"W x 9.8"H
UVP R-52 Grid Ultraviolet Lamps   R-52 Grid Lamp      The R-52 Grid Lamp's uniform source of high-intensity shortwave UV is for applications including bacteria destruction, sterilization and photochemistry.   Key Features: A filter assembly can be easily attached to convert this lamp for fluorescent analysis UVP's special UVG shortwave filter reduces solarisation, prolonging the filter life Lamp mounts securely in its transformer base or detach the lamp for movement around your work area Primary electrical cord: 8 feet (2.4m) and secondary electrical cord: 3 feet (0.9m) Dimensions: 16"L x 7.8"W x 7.8"H (406 x 198 x 198mm) Weight: 9.5 lb (4.3kg) ? UVP Portable Ultraviolet Lamps   ML-49 Portable UV Lamp    Portable UV Lamps (6 watts) are lightweight durable plastic lamps.    Key Features: Portable six-watt UV lamp has a distinctive wraparound lamp handle that comfortably balances the lamp in your hand Lamp is operated by either standard or rechargeable 6-volt batteries (two required) The optional battery charger (12V float battery charger) for use with the rechargeable batteries Mini built-in flashlight is included Portable Lamp Dimensions:  9.5"L x 2.8"W x 9.4"H	The optional C-10P Viewing Cabinet (shown) securely holds a Rechargeable UV Lamp, providing a convenient portable darkroom



Gel Documentation Systems - UVP

Capture, print and save color images for basic gel documentation with this compact, economical laboratory package. The high resolution digital camera replaces Polaroid cameras. If you currently have a Polaroid camera, check out the PhotoDoc-It Imaging System! This system provides a low cost alternative to Polaroid film! No film required! Main Features  •DigiCam 60 color camera with 10.0 megapixel resolution  •Lightweight, compact hood provides a compact darkroom environment, hood now includes a new UV blocking viewer window  •Benchtop UV Transilluminator delivers back-lit UV; select from several benchtop models  •Color printer generates instant 4" x 6" low cost, laboratory quality color prints  •Ethidium bromide filter for fluorescent stained gels  •Combination lock secures the camera to the darkroom Illuminate  Illuminate stained gels with the UV fluorescence of the compact UV transilluminator. The Ethidium Bromide emission filter, positioned inside the hood, is easily interchangeable for other filter types. Capture and View  Capture brilliant color images with the high resolution, megapixel digital color camera. View images through the new viewer window, on the camera or with the optional color LCD screen Save and Print  Save images to the memory card or instantly print images on the laboratory quality photo printer included with the system. The camera can be connected to a PC with a USB cable (not included) for transferring images.   Technical Information DigiCam 60: •Color digital camera  •10.0 megapixels •SD memory card (16 MB minimum) •Power cord included (batteries not required) Darkroom: •UV blocking viewer window •Lightweight and compact  •Handles for easy transport of the hood •Fits on top of the transilluminator Emission Filters: •EtBr Red 570-640nm Transilluminator: •The system is designed for use with UVP's Benchtop UV Transilluminators  •Select from 302nm UV or 2UV model with 302nm and 365nm •Filter sizes: 20x20cm or 21x26cm •M-20V and M-26V feature variable intensity settings Color Printer: •300 x 300 resolution  •4x6 in. prints  •USB connectivity  •108 prints included  •Dimensions: 7 x 5 x 2.5 in. (178 x 127 x 64 mm) Combination Lock: •3 digit resettable combination  •2 ft. cable

UVP Multiple Ray Ultraviolet Lamps

MRL-58 Multiple Ray Lamp	UVP’s Multiple Ray Lamps are useful in laboratory and industrial applications.
Key Features: The unique design of this lamp allows the user to pivot the lamp or change the height at three locations. Lamp includes five 8-watt tubes in different interchangeable wavelengths for use in varying applications Shortwave germicidal (254nm) light sources Longwave filtered and unfiltered UV (365nm) light sources Cool white and north sky (daylight) tubes



UVP MultiDoc-It Imaging System

This sturdy metal system is designed for multiple user laboratories for capturing gels, plates and membrane images. For TLC applications, the MultiDoc-It is available without a transilluminator. Connect to your computer loaded with UVP’s exclusive capture and camera control software!

Achieve optimum image resolution quality and fast image capture with a superior high resolution digital colour camera! The UVP Digi Camera offers unparalleled imaging results for gel documentation for those with limited budgets.

The MultiDoc-It Imaging System is configured with the Digi Camera (100). Refer to the Camera page for detailed camera descriptions and specifications.


Model Names Camera MultiDoc-It Digi Camera





Applications: The MultiDoc-It Imaging system may be used the following applications: Fluorescent & Colorimetric Samples, TLC Samples
Key Features: The enclosure provides a darkroom environment and protects the Digital Colour Camera High resolution megapixel digital colour camera for capturing gels, plates and membranes The darkroom features built-in overhead white light Optional UV lamps can be mounted in the darkroom for overhead UV illumination Safety interlock turns UV off when the door is open The camera can be used in other laboratory applications The digital colour camera connects to your existing computer for camera and software control The acquisition software, included with the systems, allows capture of quality, high resolution images and offers many features for enhancing image output:   Measurement tool for determining Rf values Multiple image resolution settings Colour and monochrome Over and under image saturation warnings Preset zoom with sample sizes Automatic and manual focus Automatic exposure and lens modes Templates for multiple users and experiments Basic and advanced capture modes Save images in multiple file formats Supports compliance with 21 CFR Part 11 Compatible with Windows 2000, XP Pro The enclosure provides a darkroom environment and protects the Digital Colour Camera

UVP Mini Ultraviolet Lamps

UVG-4,   UVSL-14P,  UVL-4 Mini-UV Lamps		Mini-UV Lamps are great for portability as these lamps are battery operated.
Key Features: Lamps are small enough to fit in a pocket Models to choose from include longwave, shortwave and longwave/ shortwave combination A nylon strap is attached for easy carrying 4 AA batteries (order separately) Dimensions:  6.25"L x 1"W x 2.2"D (159 x 25 x 56mm)
UV Lamp withFlashlight	UVL-4F Mini UV Lamp includes a longwave tube plus a flashlight in one lightweight lamp.



UVP Mineralight Display Ultraviolet Lamps

UVL-225D Mineralight Display Lamp	Mineralight display lamps use two 25-watt high performance tubes providing hours of UV illumination for fluorescence, sterilization or inspection applications. Each lamp comes with adjustable handles and mounting bracket for hanging.
Dimensions: 18.5"L x 4.75"W x 5"H (470 x 114 x 89mm) Weight: 10 lb. (4.6 kg)
Ordering Information:
Model Part Number Description Volts UVL-225D 95-0190-01 Mineralight Display Lamps 115 UVL-225D 95-0190-02 Mineralight Display Lamps 230 UVS-225D 95-0191-01 Mineralight Display Lamps 115 UVS-225D 95-0191-02 Mineralight Display Lamps 230 UVM-225D 95-0189-01 Mineralight Display Lamps 115 UVM-225D 95-0189-02 Mineralight Display Lamps 230 UVLS-225D 95-0192-01 Mineralight Display Lamps 115 UVLS-225D 95-0192-02 Mineralight Display Lamps 230



UVP Luminescent Standards

Luminescent standards for calibration of light measuring equipment and validation of data. Glowell standards provide calibration and validation of a wide range of light measurement systems while simultaneously acting as standards for experimental data.

Features:
The Glowell GLO-014 low light imaging standard (LLIS) emits light over 5 orders of magnitude. It can be used for any low light-measuring camera - for quality control or as a benchmark for between experiment comparisons. This model emits Green light with spectral peak of 525 nm. The Tritium based self-illuminating standards are used to calibrate scientific bioimaging systems (low light cameras). The use of the Tritium standards further allows direct comparison between multiple images.
For low-light calibration Extremely stable emission Peak emission at 525nm Descending light output of 100%, 10%, 1%, 0.1%, 0.01% Calibrated for quantification
Each unit contains a sealed core with a gaseous tritium light source. The level of radioactivity is 70 Bq (1.9 mCi) per unit, which conforms to international standards.
Results:
Estimating the light output from a biological sample.
Fig. 1	Chart 1
Determining the sensitivity of a CCD camera
Fig. 2	Chart 2
The Glowell Calibration Standard was used with our Biochemi HR to demonstrate the sensitivity of the camera. After 30 min of exposure, note the 3rd and 4th aperature of the luminescent standard is visible with very low background noise.

UVP Laboratory Heating Plate

UVP's Heating Plate provides a precision temperature controlled plate for maintaining a constant temperature of samples in various laboratory applications. These applications include chemiluminescent blots where temperature variation can have a dramatic effect on reproducibility. Stable temperature will give consistent day-to-day results. When imaging small animals, the heating plate supplies a uniform temperature setting to calm the animal while taking pictures.

The heating plate can be used with UVP's BioImaging Systems including the BioSpectrumAC, EC3 and ChemiDoc-It Imaging Systems.

Physical Dimensions: 3.8"H x 11.5"W x 9.7"D (97 x 292 x 246mm)  Plate: 6.4"D x 10.2"W  (163 x 259mm)

Specifications and Ordering Information Part Number 95-0412-01 (100-230V) Temperature 30°C - 40°C, preset to 39°C at factory Accuracy +1°C of readout temperature Variance Not to exceed 2°C over plate area Display LED, digital, non illuminating Heating Plate Antimicrobial coated stainless steel Power Requirements 100-230V 0.35 Amps, 50/60 Hz

Ovens - Hybridisation - UVP

HM-4000 Multidizer is designed with a variety of motion options - roller, shaker, orbital, rotating - all in one unit. Shake, rock, roll and rotate motions! Main Features  • Two independently operating compartments allow for hybridization and blotting procedures requiring different settings, temperature or motion  • The upper chamber uses a roller action to operate a shaker tray (included) or an optional orbital tray  • Temperature control (ambient to +10C to 99.9C)  • Variable speed control in lower chamber (10 to 18 rpm) enables consistent saturation of samples, for washing or hybridizing  • Large LED display shows current temperature within the chambers  • Stainless steel internal construction  • Multiple bottle sizes, arrangements and off-set bottle positions ( three bottle sizes available)  • Optional rocker plate Options Carousels:  Position the optional acrylic carousel on the rollers in the top chamber. This carousel (76-0089-01) allows additional bottle capacity and accommodates four 35 x 300 mm, eight 35 x 150 mm bottles or eight 50 ml bottles. The acrylic carousel operates at 10 - 20 rpm.  Carousel 76-0075-01 holds 10 x 50 ml conicals for placement in the upper chamber. The acrylic carousel operates at 10 - 20 rpm. Carousel kit 76-0066-01 is placed in the lower chamber and holds oversized 70 x 300mm bottles. Orbital Motion Tray:  The tray provides continuous movement for thorough mixing of samples in flasks or other containers. The tray plugs into the chamber and is controlled by the power switch.  Orbital Motion Tray: 98-0067-04 Maximum Load: 3 lbs. Rotation Speed: 30 rpm @ 2° angle Dimensions:  Tray: 10"W x 6.5"D Overall: 10.3"W x 8.2"D x 4.5"H For use of the orbital tray outside the ovens, order the following: Orbital Motion Tray, external, stand-alone, 100/115V: 98-0067-05 Orbital Motion Tray, external, stand-alone, 230V: 98-0067-06 Rocker Tray: 98-0067-03 The optional Rocker Tray provides a rocking motion and designed to accommodate various types of flasks in the HM-4000 lower chamber. The tray moves at 7 cycles/sec and up to 14 cycles/sec on the highest speed. The tray rocks at 12 degrees total (+6 degrees). To use the plate, remove the rotary wheel from oven and connect the rocker plate arm to the motor controls. Bottles:  Small bottles are made of lead-free borosilicate glass with a polypropylene cap and Teflon seal. Bottles have excellent long-term reliability. Technical Information Model HM-4000 Upper Chamber: Temperature Range: Ambient to +10C to 80C Heating Element: 500 watts Shaker Tray Speed: 54 - 106 cycles/min. Orbital Shaker: 10 - 27 cycles/sec Adjustable angle +0.1 to +7 degrees(0 to 14 degrees include angle) Lower Chamber: Temperature Range: Ambient to +10C to 99.9C Heating Element:  1200 watts Variable Speed: 10 - 18 rpm Bottle Capacity: Twenty 35 x 150 mm  Ten 35 x 300 mm Four 70 x 300 mm (with separate Carousel Kit)   Dimensions Exterior: 17.5W x 28.5H x 15D in. (445 x 724 x 381 mm) Weight: 75 lbs (34 kg)



Ovens - Hybridisation - UVP

Innovative HL-2000 HybriLinker combines the benefits of a Hybridization Oven and UV Crosslinker (254nm UV) in one self-contained, space saving unit for crosslinking prior to hybridization protocols. Main Features  The hybridization oven features: • This unique, new design for the Life Science Laboratory allows crosslinking and hybridization at one location  • Hybridization oven and crosslinker operate independently of each other  • Temperature control (ambient to +10C to 99.9C)  • Variable speed control (10 to 15 RPM) enables consistent saturation of samples, whether it be for washing or hybridizing  • Large LED display is easily readable  • Drip trays catch spills  • Stainless steel internal construction aids in maintaining a clean environment  • Multiple bottle sizes, arrangements and off-set bottle positions  • Optional rocker plate allows use of various types of flasks The crosslinker chamber features:  • Shortwave 254nm, 8 watt, ultraviolet tubes supply uniform overhead UV illumination  • Preset and manual controls for ultraviolet or time exposures  • Preset exposure delivers 120,000 microjoules or five minutes of exposure  • Microprocessor measures and controls UV output, ensuring maximum energy efficiency  • Large LED display continuously displays time or energy settings  • Tactile membrane switch keypad  • Window on the door allows viewing of the process yet blocks out the UV exposure  • Pull-out drawer provides easy access for placement of samples  • Crosslinker is available as a separate unit (see UV Crosslinkers) Options Orbital Motion Tray:  The tray provides continuous movement for thorough mixing of samples in flasks or other containers. The tray plugs into the chamber and is controlled by the power switch.  Orbital Motion Tray: 98-0067-04 Maximum Load: 3 lbs. Rotation Speed: 30 rpm @ 2° angle Dimensions:  Tray: 10"W x 6.5"D Overall: 10.3"W x 8.2"D x 4.5"H For use of the orbital tray outside the ovens, order the following: Orbital Motion Tray, external, stand-alone, 100/115V: 98-0067-05 Orbital Motion Tray, external, stand-alone, 230V: 98-0067-06 Rocker Tray: 98-0067-03 The optional Rocker Tray provides a rocking motion and designed to accommodate various types of flasks in the HL-2000. The tray moves at 7 cycles/sec and up to 14 cycles/sec on the highest speed. The tray rocks at 12 degrees total (+6 degrees). To use the plate, remove the rotary wheel from oven and connect the rocker plate arm to the motor controls. Bottles: Small bottles are made of lead-free borosilicate glass with a polypropylene cap and Teflon seal. Bottles have excellent long-term reliability. Technical Information Model HL-2000 Variable Speed: 10 to 15 RPM Heating Element: 1250 watts Operation Range: Ambient to +10C to 99.9C Temperature Controller Accuracy: +0.1C Temperature Display: LED Temperature Stability: Inside Oven: +0.3C to 68C Inside Bottles: +0.1C to 68C Temperature Uniformity: Inside Oven: +0.1C to 68C Inside Bottles: +0.1C to 68C Interior Dimensions: 14"W x 10.75"H x 10.75D (356 x 273 x 273mm) Bottle Capacity: Twenty (20) 35 x 150 mm Ten (10) 35 x 300 mm Power: 12V AC/DC from 115V/60Hz or 230V/50Hz Crosslinker • Pre-set or user-selected UV energy or UV time exposure settings  • Maximum UV energy setting of 999,900 microjoules per cm2  • LED displays time or energy  • Internal interlocking UV safety system  • Tactile membrane keypad  • Five 8-watt, 254nm shortwave dual bipin discharge tubes



UVP High Performance Transilluminators

TFM-20

Exclusive 25-watt tubes provide 100-watts of high intensity performance and uniform UV illumination



Key Features:

• High performance 25-watt UV tubes for high fluorescence and sensitivity on stained gels

• Stainless steel cover frame provides for easy cleaning and reduces contamination of samples

• Uniform, brilliant back-lit fluorescence illumination is enhanced with UVP's unique background uniformity screen and UVG long-life filter

• Uniformity screen is available on units with midrange or longwave UV

• The transilluminator's powerful cooling fan maintains a low filter surface temperature to avoid sample damage and maintains a constant UV intensity

• The removable and adjustable protective UV blocking cover is included with each transilluminator

Transilluminator with background uniformity screen



Transilluminator without background uniformity screen



WARNING: Transilluminators are powerful sources of ultraviolet radiation which can cause serious damage to unprotected eyes and skin.



Ordering Information:

Model	Part No. 115V	Part No. 230V	Intensity Style	Wavelength	Filter Size
TFM-20	95-0286-01	95-0286-02	Hi/Low	302nm	20x20cm
TFM-26	95-0285-01	95-0285-02	Hi/Low	302nm	21x26cm
TFM-30	95-0302-01	95-0302-02	Hi/Low	302nm	25x30cm
TFM-40	95-0283-04	95-0283-05	Hi/Low	302nm	20x40cm
TFS-20	95-0319-01	95-0319-02	Hi/Low	254nm	20x20cm
TFS-26	95-0320-01	95-0320-02	Hi/Low	254nm	21x26cm
TFS-30	95-0321-01	95-0321-02	Hi/Low	254nm	25x30cm
TFS-40	95-0322-01	95-0322-02	Hi/Low	254nm	20x40cm
TFML-26E	95-0308-01	95-0308-02	Single	302/365nm	21x26cm
TFML-40E	95-0309-01	95-0309-02	Single	302/365nm	20x40cm
TFML-20E	95-0323-01	95-0323-02	Single	302/365nm	20x20cm
TFML-30E	95-0324-01	95-0324-02	Single	302/365nm	25x30cm
TFL-40	95-0283-01	95-283-02	Hi/Low	365nm	20x40cm



Useful Information:
UVP refers to its midrange UV products as 302nm. Other manufacturers may say 300nm, 310nm or 312nm. The spectral output of these units is the same as UVP's 302nm.

Safety certifications:
All 115V models "US and C entela" certified for US and Canada; 230V CE certified for European Community. 100V models available (T marked for Japan).



Ovens - Hybridisation - UVP Click here to request a quotation.

HB-1000 Hybridizer hybridization oven is designed to create the ideal environment for nucleic acid hybridization. The HB-1000 is an efficient work space ensuring thorough mixing at a set temperature. Main Features • Microprocessor allows precise selection of temperature control (ambient to +10C to 99.9C)  • Variable speed control (10 to 15 RPM) of the carousel enables consistent saturation of samples, whether for washing or hybridizing  • Adjustable RPM knob lets you slow down the rotary wheel for removal of samples  • A large LED, which displays the current temperature inside the chamber, is situated above a touch sensitive key pad for temperature control  • The rotary wheel can be removed and replaced with an interchangeable rocker plate enabling all hybridization protocols in one benchtop unit  • Removable protective tray allows easy cleanup of spilled media  • The rotary wheel can hold twenty (20) 35 x 150mm or ten (10) 35 x 300mm or combination of bottles  • Use multiple bottle sizes, arrangements and off-set bottle positioning  • Stainless steel internal construction can be cleaned easily  • Optional rocker plate allows use of various types of flasks Options Orbital Motion Tray:  The tray provides continuous movement for thorough mixing of samples in flasks or other containers. The tray plugs into the chamber and is controlled by the power switch.  Orbital Motion Tray: 98-0067-04 Maximum Load: 3 lbs. Rotation Speed: 30 rpm @ 2° angle Dimensions:  Tray: 10"W x 6.5"D Overall: 10.3"W x 8.2"D x 4.5"H For use of the orbital tray outside the ovens, order the following: Orbital Motion Tray, external, stand-alone, 100/115V: 98-0067-05 Orbital Motion Tray, external, stand-alone, 230V: 98-0067-06 Rocker Tray: 98-0067-03 The optional Rocker Tray provides a rocking motion and designed to accommodate various types of flasks in the HB-1000. The tray moves at 7 cycles/sec and up to 14 cycles/sec on the highest speed. The tray rocks at 12 degrees total (+6 degrees). To use the plate, remove the rotary wheel from oven and connect the rocker plate arm to the motor controls. Bottles: Small bottles are made of lead-free borosilicate glass with a polypropylene cap and Teflon seal. Bottles have excellent long-term reliability. Technical Information Model HB-1000 Variable Speed: 10 to 15 RPM Heating Element: 1250 watts Operation Range: Ambient to +10C to 99.9C Temperature Controller Accuracy: +0.1C Temperature Display: LED Temperature Stability: Inside Oven: +0.3C to 68C Inside Bottles: +0.1C to 68C Temperature Uniformity: Inside Oven: +0.1C to 68C Inside Bottles: +0.1C to 68C Bottle Capacity: Twenty (20) 35 x 150 mm or Ten (10) 35 x 300 mm Power: 12V AC/DC from 115V/60Hz or 230V/50Hz Dimensions: Interior: 14W x 10.75H x 10.75:D in.(356 x 273 x 273mm) Exterior: 17.5W x 16H x 16D in. (445 x 406 x 381mm)



Ovens - Hybridisation - UVP Click here to request a quotation.

HB-500 Minidizer is a personal desktop hybridization oven ideal for use in laboratories with low usage and space requirements. Main Features  • Compact size is excellent for limited bench space • Rotation speed set at 12 rpm  • Precision temperature controls  • Bottle capacity of four 35 x 150mm bottles, four 50 ml and eight 15 ml conical plastic bottles • Consistent, repeatable results achieved with microprocessor controls  • Chamber interior is stainless steel fabrication with a 3/8" beta blocking acrylic cover  • Cover swings down for easy access to the bottle carousel  • Carousel pops out of chamber for easy insertion or removal of bottles Options Small bottles are made of lead-free borosilicate glass with a polypropylene cap and Teflon seal. Bottles have excellent long-term reliability. Technical Information Model HB-500 Temperature Range: Ambient to +10C to 80C Heating Element: 500 watts Speed: 12 rpm Construction: Stainless steel interior 3/8" acrylic cover Bottle Capacity: Four 35 x 150 mm or Four 50 ml or Eight 15 ml Dimensions: Internal: 9H x 13W x 8D in. (229 x 330 x 203mm) 8.5"W x 8.5"D x 6.6"H (at the back of the unit)



UVP Handheld Ultraviolet Lamps

UVGL-55 Handheld UV Lamp		Handheld UV Lamps (6 watts) come with an ergonomically designed handle.
Key Features: Lamps are lightweight. Models available include shortwave, longwave UV or a combination shortwave/longwave version Combination version comes with a snap-on wavelength selector for switching between wavelengths Use these lamps with the J-129 Lamp Stand (pictured) or the C-10 Cabinet Handheld Lamp Dimensions:  14.9"L x 3.2"W x 2.5"H Lamp Stand Dimensions: 9.5"H x 13"L
UVP Grid Display Ultraviolet Lamps   UVGD-68 Grid Display Lamp      The UVGD-68 uses a high-intensity, shortwave quartz grid lamp.  The high-performance lamp provide hours of UV for display fluorescence, sterilization or inspection applications.   Key Features: This shortwave, high intensity UV lamp is rated at 20,000 hours of use Unlimited on/off capability Excellent for large scale mineral displays The UVG Long-Life Filter is included Adjustable handles/brackets are supplied for easy mounting Dimensions: 18.5"L x 4.75"W x 5"H (470 x 121 x 127mm); Weight: 10 lb (4.6kg)	J-129 Lamp Stand with  Handheld Lamp



UVP GelDoc-It & GelDoc-It TS Imaging Systems

GelDoc-It  Maximize gel documentation with the modular GelDoc-It Imaging System. The gel imaging system features the new four position filter array for use of a variety of emission filters. The modular design allows you to add components to maximize the capabilities of the system as needed for fluorescent and colorimetric gel imaging. The system can be configured with a standard lens or a motorized lens to automate your research. Main Features  •New high resolution 2.0 GelCam 310 CCD camera •Zoom lens: motorized or manual •Software interface controls the motorized zoom lens •Modular design - add additional emission filters, epi UV lights, white light plate or UV converter plates to maximize gel fluorescence capabilities •New optional white light LED plate plugs into the darkroom for uniform white light illumination; convenient storage pocket on the darkroom •Light tight darkroom with overhead white light, large access door and unique gel viewing window  •New filter array feature four positions for adding additional filters as needed; EtBr filter included •Built-in overhead white light •Slide out tray hold UV transilluminator •Select from several benchtop, patented and awarding winning transilluminator models (configured with system or optional) •VisionWorksLS Software (configured with system or optional) Transillumination  •To use the transilluminator, slide the transilluminator out on the sliding tray and place samples on the filter surface •Photo shows the FirstLight Uniform UV illuminator •To fluoresce samples in the 460-470mm range, place the optional Visi-Blue Plate over the transilluminator surface •To visualize coomassie blue and silver stained samples, place the optional UV to White Light Converter Plate on top of the transilluminator Epi Illumination  •Add UV modules for overhead UV illumination •Modules are positioned on two sides of the darkroom VisionWorksLS Image Acquisition and Analysis Software  VisionWorksLS Image Acquisition and Analysis Software can be configured with the system or ordered separately. Check with your local representative for details. This sophisticated package provides comprehensive tools for image capture and analysis of gels, plates and membranes as well as colony counting. Capabilities include: •Image acquisition functions for simple image capture and expanded integration options  •Apply numerous image enhancements to images  •Comprehensive tools for advanced 1D lane densitometry and analysis including area density, molecular weights and colony counting  •Support for 21 CFR Part 11 compliance  •One-touch automated macros  •Define user profiles and preferences  •Generate extensive reports and export data  •Multiple user network license available   GelDoc-It TS Screen tilts to optimum viewing angle. A built-in computer touch screen supplies a complete system at one location for fluorescent and colorimetric imaging. This self-contained gel imaging system features a scientific grade CCD camera for capturing high resolution images with simple yet versatile capture and save options. The modular design allows you to add a white light illuminator or converter plates and UV modules to maximize the capabilities of the system as needed.  Main Features  •Fluorescent and colorimetric imaging  •New high resolution 2.0 GelCam 310 CCD camera  •Touch screen technology and built in computer for fast, easy imaging  •Front mounted USB port for saving images  •Transfer images via network or FTP  •Modular design - add additional emission filters, epi UV lights, white light plate or UV converter plates to maximize gel fluorescence capabilities  •New optional white light LED plate plugs into the darkroom for uniform white light illumination; convenient storage pocket on the darkroom  •EtBr Filter fits in the slide-out tray under the camera for easy access Software Interface  Capture, view, save and print images with the touch screen technology: •See a LIVE preview of gels, plates and colonies  •SNAP (capture) the image  •SAVE the image in TIFF (8, 12 or 16-bit), BMP or JPEG file formats  •PRINT to any digital printer  •Set the TIME/DATE, exposure warnings and integration times Transillumination  •To use the transilluminator, slide the transilluminator out on the sliding tray and place samples on the filter surface  •Photo shows the FirstLight Uniform UV illuminator  •To fluoresce samples in the 460-470mm range, place the optional Visi-Blue Plate over the transilluminator surface  •To visualize coomassie blue and silver stained samples, place the optional UV to White Light Converter Plate on top of the transilluminator Epi Illumination  •Add UV lamps for overhead UV illumination •Four watt UV lamp with 254 and 365nm UV - Model UVGL-25  •Position lamps on two sides of the darkroom for uniform illumination   Technical Information   GelDoc-It GelDoc-It TS Darkroom: •Lightweight plastic •Access door •Gel viewer •Cap protects camera from exposure to environmental element •Built-in computer with USB ports •15 inch VGA touch screen •Wide access door with UV safety shutoff •Gel viewing window •Sliding tray for transilluminator •Epi white illumination Emission Filters: •Four position filter array •EtBr Red 570-640nm •EtBr Red 570-640nm Software: •Camera controls •Image capture •Image enhancement •Windows 2000 SP4, Windows XP Pro SP2 •Windows 2000 SP4, Windows XP Pro SP2 Transilluminator: •Select from FirstLight or Benchtop Transilluminators •Select from FirstLight or Benchtop Transilluminators



UVP Gel Tools



Gel Trays, Gel-Scooper,  Gel-Cutter, Gel-Ruler	Gel tools are helpful for researchers working with transilluminators and gel imaging systems.  Fluorescent Standard Step Tablet   Gel-SentryTM DNA Preparation Plate
Key Features: The Gel-Cutter's edge allows for easy cutting and removal of gel material. Gel-Scooper, made of strong acrylic with a beveled edge, is designed for easy transfer of gels from electrophoresis equipment to viewing equipment. Gel-Trays (in two sizes), made of UV transmitting plexiglas, can be used for moving gels to the transilluminator. The tray protects the transilluminator's filter surface from scratches. side panels on the Gel-Tray, angled at a 45 degree bend, extend upward from the tray surface for easy handling. Two sizes available The Gel-Ruler has centimeter markings that fluoresce under 365nm and 302nm ultraviolet wavelengths, providing reference marks for DNA analysis.
Fluorescent Standard Step Tablet	Fluorescent Standard Step Tablet  Place the non-photo bleaching Fluorescent Standard Step Tablet (patent pending) next to your gel on a FirstLight UV Illuminator. The step tablet has a calibrated 21-step gradation with density from totally clear (step 1) to totally opaque (step 21). The gradation on the step tablet allows accurate, consistent comparison of the bands and spots on acquired images for variations in lighting and optical conditions and for maximizing fluorescence calibration of images. The guide lets researchers evaluate the image against the values of gray, maximizing fluorescence calibration and providing a standard reference for images.
Gel-SentryTM DNA Preparation Plate	Gel-SentryTM DNA Preparation Plate  Unique design features UV blocking panels to protect the gel from damaging UV. The layers of panels can be aligned to isolate specific lanes and bands to minimize UV exposure during cutting. Place gels on the top UV transmitting glass plate. The sliding acrylic panels below are 98% UV blocking at 302nm UV.

UVP Fraud Detection Ultraviolet Lamps

SL-2M Fraud Detection UV Lamp	SL-2M Fraud Detection UV Lamps use longwave ultraviolet light to check the authenticity of signatures, documents, tickets, passports, credit cards and currency.
Key Features:  These UV lamps offer a cost-effective solution to security problems as the lamps detect invisible markings and alterations made to documents. Lamp is easy to operate. Simply pass the item in question under the longwave ultraviolet. Invisible inks or altered documents fluoresce when exposed to the UV.  Other UV lamps for fraud detection: UVL-23RS, UVL-4. Speed up customer service Instant document verification Deter criminals Easily detect forged documents, currency and signatures Easy to operate Safe to use  Dimensions: 6.5"W x 5.75"D x 4.5"H

UVP FirstLight UV Illuminator

FirstLight® UV Illuminator			Maximize your quantitative imaging with the new FirstLight® UV Illuminator! Unique design provides extremely uniform UV illumination, which is critical for accurate quantitative analysis. UVP has received the prestigious "Photonics Circle of Excellence" Award from Laurin Publishing for the FirstLight® UV Illuminator! The award recognizes this instrument as a technically innovative product.
Key Features: High sensitivity and dynamic range are consistent across the illumination surface Software correction of uniformity is no longer required Accurate gel to gel comparison Uniformity now supplies <5% coefficient of variance (CV) across the full filter area Used with UVP’s BioImaging Systems’s CCD camera provides a low cost solution compared to laser scanning Compact size Illuminator includes a Gel-Cutter, Focus Target and UV Blocking Cover
	This image, taken with a UVP BioImaging System, shows the uniformity across the full filter area
Applications: The FirstLight® UV Illuminator represents a unique highly uniform excitation source for quantitative fluorescent imaging in a wide range of genomic and proteomic applications: Electrophoretic separation and quantiation of 1D and 2D protein separations Solid phase immunoassay DNA quantitation RNA quantitation Application Note describes use of the FirstLight® UV Illumination instrument for use in quantitative DNA and protein analysis. Dimensions: 11”D x 14”W x 5.63”H (279x356x143mm)



UVP EL Series Ultraviolet Lamps

		All EL Lamps can be placed in the J-138 Universal Lamp Stand for hands-free operation. The lamp easily slips into the metal clip for hands-free use.
Viewing Cabinets are also available for use with the lamps. UVP's C-65 Cabinet accommodates one or two of the 8 watt EL Lamps for illuminating specimens in darkroom conditions.
EL Series Lamp Dimensions: 4 Watt EL Lamps: 9.8"L x 3.8"W x 2.5"D  6 Watt EL Lamps: 12"L x 3.8"W x 2.5"D 8 Watt EL Lamps: 14.8"L x 3.8"W x 2.5  Lamp Stand Dimensions: 10.74"H x 13"L x 3"W

UVP EC3 Imaging System

Manually controlled system offers operation of the darkroom within easy reach. The light tight darkroom supplies optimum conditions for many imaging applications including chemiluminescence, fluorescence, bioluminescence and colorimetric imaging.  New transilluminator design supplies increased performance and efficiency. Product enhancements include a new electronic ballast and cutting-edge construction! Main Features  •Assortment of CCD cameras including deeply cooled cameras •Application templates •Five-position emission filters •Unique viewing window is UV blocking for quick sample inspection •Easy access fold-down white light plate •Chemi tray fits over the plate for placement of blots •Roll-out tray provides easy access to the UV transilluminator •Select from several benchtop, patented and awarding winning transilluminator models (system may be configured with software or optional, check with your UVP representative) •VisionWorksLS Software (system may be configured with software or optional, check with your UVP representative) •BioLite ready Transillumination  •The white light plate folds down for illuminating samples such as coomassie blue stained or silver stained media •Operate the white light via the software interface •Flip the plate back when not in use •To use the transilluminator, slide the transilluminator out on the sliding tray and place samples on the filter surface •To fluoresce samples in the 460-470mm range, place the optional Visi-Blue Plate over the transilluminator surface Chemiluminescent Imaging  •The Chemi HR, BioChemi HR and OptiChemi HR cameras are cooled CCD cameras recommended for chemiluminescent imaging •Photo shows the BioChemi HR camera •For chemiluminescent applications, the place the chemi tray on top of the white light plate for placement of blots •Adjust the height of the tray to specific, repeatable positions BioLite MultiSpectral Source (optional)  •For fluorescent plant imaging, place the BioLite tray inside the darkroom •The BioLite supplies a direct source using fiber optic bundles and a closed optical path to tightly control the output spectrum for consistent, repeatable measurements with superior signal to noise ratio •The kit includes an emission and excitation filter set •Link to the BioLite for more information … VisionWorksLS Image Acquisition and Analysis Software  VisionWorksLS Image Acquisition and Analysis Software can be configured with the system or ordered separately. Check with your local representative for details. This sophisticated package provides comprehensive tools for image capture and analysis of gels, plates and membranes as well as colony counting. Capabilities include: •Image acquisition functions for simple image capture and expanded integration options •Apply numerous image enhancements to images •Comprehensive tools for advanced 1D lane densitometry and analysis including area density, molecular weights and colony counting  •Support for 21 CFR Part 11 compliance •One-touch automated macros •Define user profiles and preferences •Generate extensive reports and export data •Multiple user network license available Technical Information Darkroom: •Light tight •Wide access door with UV safety shutoff •Gel viewing window •Sliding tray for transilluminator •Epi white and UV illumination (365nn and 254nm) Emission Filters - five positions: •SYBR Green 515-570nm •SYBR Gold 485-655nm •EtBr Red 570-640nm Software: •VisionWorksLS (system may be configured with software or optional, check with your UVP representative) •Windows 2000 SP4, Windows XP Pro SP2 Transilluminators: •Select from FirstLight or Benchtop models



UVP DigiDoc-It Imaging System



The DigiDoc-It System connects to your existing computer for a digital imaging system designed for low cost image acquisition and documentation of gels, plates and membranes.

Achieve optimum image resolution quality and fast image capture with a superior high resolution digital colour camera! The UVP Digi Camera offers unparalleled imaging results for gel documentation for those with limited budgets.

The DigiDoc-It System is configured with the Digi Camera (100). Refer to the Camera page for detailed camera descriptions and specifications.



Model Names Camera DigiDoc-It Digi Camera







Applications: The DigiDoc-It System may be used the following applications: Fluorescent & Colorimetric Samples
Key Features: This economical system combines a high resolution megapixel digital colour camera for capturing gels, plates and membranes, lightweight compact hood with viewport and easy access door Digital colour camera connects to your existing computer for camera and software control System is designed to mount over a large format 25-watt High Performance UV Transilluminator or if a smaller transilluminator is preferred, order an 8-watt Benchtop UV Transilluminator and drawer combination Acquisition software, included with the systems, allows capture of quality, high resolution images and offers many features for enhancing image output:   Measurement tool for determining Rf values Multiple image resolution settings Colour and monochrome Over and under image saturation warnings Preset zoom with sample sizes Automatic and manual focus Automatic exposure and lens modes Templates for multiple users and experiments Basic and advanced capture modes Multiple file format compatibility Supports compliance with 21 CFR Part 11
Accessories: Thermal Printer Doc-ItLS Analysis Software Drawer - The DigiDoc-It drawer is designed for use with a compact Benchtop UV Transilluminator	DigiDoc-It drawer
Transilluminators:  Transilluminators are ordered separately. Choose from High Performance 25-watt transilluminators or combine the system with an eight-watt Benchtop UV Transilluminator and drawer. .

UVP Converter Plates

UV to White Light Converter Plates
		UV to white light converter plates.  A specially designed plate converts a transilluminator's ultraviolet radiation to white light for viewing protein gels, coomassie blue stained or silver stained media.
Key Features: A specially designed plate converts a transilluminator's ultraviolet radiation to white light for viewing protein gels, coomassie blue stained or silver stained media. The Converter Plate's uniquely phosphored glass assembly (patent pending) converts the UV radiation via a white diffuser. The scratch-resistant glass is mounted in a metal housing for durability. Handles are situated on two sides of the plate for easy handling. Two plates are available for covering transilluminator filter surface sizes up to 21 x 26cm or 20 x 40cm. Custom sizes are also available.
Ordering Information:
Product Part No. Filter UV to White Light 38-0191-01 21x26cm UV to White Light 38-0191-02 20x40cm UV to White Light 38-0191-04 25x26cm

Visi-Blue Plates
Click for larger picture		The Visi-Blue Plates convert 302nm to 480nm blue light for use with SYBR Green, SYPRO Orange and GFP stains.
Key Features: Minimize photonicking of DNA samples Amber protective cover blocks blue light transmission and allows visualization of stained samples above 500nm Two filter sizes (21x26cm or 20x40cm) available for placement over a UV transilluminator Scratch resistant glass surface is safety fused into metal frame



UVP Compact Ultraviolet Lamps

UVG-11 Compact UV Lamp			Compact UV Lamps (4 watt lamps) fit comfortably in the hand. This lamp is available in 115V or 230V versions.
Key Features: Combination version comes with a snap-on wavelength selector for switching between wavelengths Lightweght, easy-to-handle lamp design The Compact UV Lamp comes in a 12 Volt style (for cigarette lighter operation) which is designed for windshield curing Use Compact UV Lamps with J-124 Lamp Stand or the C-10 Chromato-Vue Viewing Cabinet for viewing materials in a darkened environment Models available include shortwave, longwave or a combination shortwave/longwave version Compact Lamp Dimensions 7.8"L x 2.8"W x 2.1"D Lamp Stand Dimensions: 9.75"H x 13"L
		J-124 Lamp Stand with Compact UV Lamp. UVP
UVP ChromaDoc-It TLC Imaging System   ChromaDoc-It includes overhead UV to fluoresce brilliant TLC colour images. Achieve optimum image resolution quality and fast image capture with a superior high resolution digital colour camera! The UVP Digi Camera offers unparalleled imaging results for gel documentation for those with limited budgets. The ChromaDoc-It TLC Imaging System is configured with the Digi Camera (100). Refer to the Camera page for detailed camera descriptions and specifications.   Model Names Camera ChromaDoc-It Digi Camera       Applications: The ChromaDoc-It Imaging system may be used the following applications: Fluorescent & Colorimetric Samples, TLC Samples Key Features:   The low profile cabinet features built-in overhead UV with 15-watt shortwave and longwave UV tubes positioned on two sides of the cabinet for uniform illumination for fluorescence studies Interior overhead white light is included in the cabinet High resolution megapixel digital colour camera for capturing gels, plates and membranes Use your existing computer loaded with UVP’s acquisition software for camera control and image capture functions The acquisition software allows capture of quality, high resolution images and offers many features for enhancing image output:    Measurement tool for determining Rf values Multiple image resolution settings Colour and monochrome Over and under image saturation warnings Preset zoom with sample sizes Automatic and manual focus Automatic exposure and lens modes Templates for multiple users and experiments Basic and advanced capture modes Save images in multiple file formats Supports compliance with 21 CFR Part 11 Compatible with Windows 2000, XP Pro Accessories: Thermal Printer Doc-ItLS Analysis Software

UVP Cameras for BioImaging Systems

UVP offers a wide range of advanced scientific-grade, monochrome CCD cameras designed for various imaging applications.  New! 4 megapixel cooled CCD BioChemi HR camera for exceptional image quality! The OptiChemi HR high resolution, deeply cooled CCD camera captures a full range of imaging samples including luminescence and chemiluminescence. Other cameras include the Chemi HR Camera, Gel HR Camera and Fluor Camera. Talk to a UVP BioImaging Systems Specialist about a camera that's right for your budget and imaging requirements. Camera description, specifications applications are provided below.   Camera Descriptions OptiChemi HR Camera The camera is an advanced, monochrome CCD camera for extra long exposure times. Intense cooling and low noise give a wide dynamic range for applications with longer integration for bioluminescence applications. Provide superior quantum efficiency for chemiluminescence. BioChemi HR Camera Chosen for sensitivity, this monochrome CCD camera is designed specifically for the Western Blots. The camera is cooled to subzero temperatures, produces low background noise and a wide dynamic range for high quality images in a short exposure time, excellent for chemiluminescence. Chemi HR Camera Suitable for high resolution imaging, this cooled CCD camera can also be applied to general purpose chemiluminescent, fluorescent or white light imaging. The camera can be used in molecular biology and pharmaceutical laboratories. Gel HR Camera Monochrome high resolution megapixel, non-cooled CCD camera for laboratories performing routine electrophoresis of DNA and protein gels. Fluor Camera This monochrome CCD camera is designed for basic gel documentation applications. This camera is excellent for multiple user laboratories with large volume image capture requirements.   Camera Applications       Ultraviolet (UV) - Cabinets - UVP       UV Viewing Cabinets Overview Chromato-Vue Viewing Cabinets from UVP provide a darkroom environment for viewing materials. The comfortable soft rubber viewport utilizes a contrast control viewing filter. This filter protects the eyes from harmful shortwave radiation and blocks the "blue haze" associated with longwave UV. Viewport has adequate space for eyeglasses. A lightweight access curtain allows for easy entry and blocks out external light. A variety of cabinets are available to choose from including mini cabinets for viewing minerals and education uses to larger cabinets for applications such as chromatography. Mini UV Viewing Cabinets Mini Chromato-Vue Viewing Cabinets provide a compact darkroom environment for viewing materials. All cabinets feature a contrast control filter that absorbs UV energy to protect the eyes. Photo shows the C-10 Cabinet with a Handheld UV Lamp or purchased as G-15G which is a set. Main Features •  Each cabinet is designed to be used with specific UVP lamp models, which fit snugly on top of the cabinet  •  Mini viewing cabinets are constructed with a metal base and plastic top  •  The bottom panel of the cabinet is removable  •  A contrast control filter absorbs UV energy to protect the eyes  •  Soft rubber viewport provides a comfortable viewing area with adequate space for eyeglasses  •  Lightweight access curtain blocks out external light from the cabinet interior Options  •  Rechargeable Lamps •  Compact and Handheld Lamps •  EL Series Lamps   Technical Information Model Mini UV Fabrication: Metal base, plastic top Viewport: Software rubber with UV blocking contrast control filter Curtain: Lightweight materials blocks ambient light Dimensions: (mm) LxWxH Int. 229x254x178 Ext. 229x267x305 Weight: 1.6 kg     Ultraviolet (UV) - Cabinets - UVP   UV Viewing Cabinets Overview Chromato-Vue Viewing Cabinets from UVP provide a darkroom environment for viewing materials. The comfortable soft rubber viewport utilizes a contrast control viewing filter. This filter protects the eyes from harmful shortwave radiation and blocks the "blue haze" associated with longwave UV. Viewport has adequate space for eyeglasses. A lightweight access curtain allows for easy entry and blocks out external light. A variety of cabinets are available to choose from including mini cabinets for viewing minerals and education uses to larger cabinets for applications such as chromatography. Mid Size UV Viewing Cabinets Multifunctional Chromato-Vue Viewing Cabinet provides a darkroom environment for viewing materials. The C-65 accommodates one or two of the eight watt EL Series Lamps. Main Features •  The C-65 Chromato-Vue Cabinet is designed to accommodate one or two of the EL Series 8-watt lamps (ordered separately)  •  Use of two lamps illuminates the cabinet's interior from two sides of the cabinet  •  Lamps are removable from the cabinet for use in other applications  •  Lamps come with a universal plug which connects directly to the C-65 Cabinet, plus a supplementary power cord to plug into a line current for operating the lamp in other applications  •  The C-65 includes an interior overhead white light  •  The bottom panel of the cabinet is removable  •  Soft rubber viewport and contrast control filter that absorbs UV energy to protect the eyes  •  Lightweight access curtain blocks external light  •  A camera mount can be used for photodocumentation - contact UVP for CCD camera information Options  •  EL Lamps •  CCD Camera - contact UVP for options Technical Information Model C-65 Cabinet Light Sources: White Light - Order EL Lamps separately UV Lamps (order EL Lamps separately) Power switches: Located on top of unit Viewport: With UV blocking filter Dimensions: (mm) LxWxH Int. 432x356x153 Ext. 502x419x400 Weight: 6.1 kg     Ultraviolet (UV) - Cabinets - UVP   UV Viewing Cabinets Overview Chromato-Vue Viewing Cabinets from UVP provide a darkroom environment for viewing materials. The comfortable soft rubber viewport utilizes a contrast control viewing filter. This filter protects the eyes from harmful shortwave radiation and blocks the "blue haze" associated with longwave UV. Viewport has adequate space for eyeglasses. A lightweight access curtain allows for easy entry and blocks out external light. A variety of cabinets are available to choose from including mini cabinets for viewing minerals and education uses to larger cabinets for applications such as chromatography. Large UV Viewing Cabinets The large UV Chromato-Vue viewing cabinets feature a removable bottom panel so the cabinet may be placed over large samples or a transilluminator. Cabinets include high intensity 15-watt UV. C-70G Cabinet pictured. Main Features •  Large UV Viewing Cabinets include C-70G, C-71 and C-75 models  •  A soft rubber viewport includes a contrast control filter.  •  Control switches are conveniently located for selecting either of the UV wavelengths or the interior overhead white light  •  Easy access to the cabinet interior is via the curtain which also blocks ambient light  •  The C-70G Chromato-Vue Cabinet includes two each of 15-watt shortwave and longwave UV tubes mounted on one side of the cabinet  •  Model C-71 is similar to the C-70G, but has four 15-watt, longwave UV tubes on one side of the unit  •  The 254nm and 365nm UV tubes in the C-75 are positioned on two sides of the cabinet providing uniform UV illumination for fluorescence studies  •  Cabinets are manufactured from lightweight plastic Options  The C-75 cabinet can be used for photodocumentation imaging applications. Contact UVP for details on a CCD camera for use this cabinet. Technical Information Model C-70 Cabinet C-71G Cabinet C-75 Cabinet UV Source: 254nm and 365nm 365nm 254nm and 365nm Watts: 15 Watts (two tubes each wavelength)  Overhead white light 15 Watts (four tubes) Overhead white light 15 Watts Dimensions: (mm) WxDxH Int. 533.4x330x203 Ext.594x401x330 Int. 432x356x168 Ext. 502x419x400 Weight: 10.3 kg 10.3 kg 8 kg     UVP BL15 Bench Ultraviolet Lamps   BL-15 Illumination Lamp      This longwave BLB UV lamp is ideal for inspection applications in hard-to-reach places.   Key Features: The lamp’s long, narrow housing is durable, lightweight and easy to handle Two adjustable hooks are included Dimensions: 20"L x 2"Dia (508 x 50.8mm); Weight: 2.5 lb (1.1kg)   UVP BioSpectrum Imaging System   The BioSpectrum® Imaging System is designed to automate your research with one-touch, pre-set or user-defined controls for accurate, repeatable imaging and analysis for chemiluminescent, bioluminescent, fluorescent, colorimetric imaging. The BioSpectrum is faster than film for western blot imaging. Main Features   •Faster than film for western blot imaging •Assortment of CCD cameras including deeply cooled cameras •Motorized optics for setting the aperture, zoom and focus •Automated templates for repeat experiments •Light tight darkroom creates optimum imaging conditions •Unique viewing window is UV blocking for quick sample inspection •Built-in overhead white light and UV are easily selected from the software interface •Automated control of the five-position emission filter array •Easy access fold-down white light plate •Chemi tray fits over the plate for placement of blots •Roll-out tray provides easy access to the UV transilluminator •Select from several benchtop, patented and awarding winning transilluminator models (configured with system or optional) •VisionWorksLS Software (configured with system or optional) •BioLite ready Software Interface  •Automates your research for easy, yet accurate and repeatable results •Controls the motorized zoom lens, epi and transillumination UV and white light, emission filter selection and system power •Allows selection of user-defined or default settings •Select identify new filters or select from SYBR Green (515-570mm), SYBR Gold (485-655mm), EtBr (570-640mm), clear and empty positions •Click on the epi and transillumination light sources •Set templates and user preferences for recurring experiments Transillumination •The white light plate folds down for illuminating samples such as coomassie blue stained or silver stained media •Operate the white light via the software interface •Flip the plate back when not in use •To use the transilluminator, slide the transilluminator out on the sliding tray and place samples on the filter surface •To fluoresce samples in the 460-470mm range, place the optional Visi-Blue Plate over the transilluminator surface Chemiluminescent Imaging •The Chemi HR, BioChemi HR and OptiChemi HR cameras are cooled CCD cameras recommended for chemiluminescent imaging •For western blot and other chemiluminescent blots applications, place blots on the removable chemi tray •For chemiluminescent applications, place the chemi tray on top of the white light plate for placement of blots •Adjust the height of the tray to specific, repeatable positions •For western blot imaging, for application use information refer to the article titled "Ultra-Rapid and Ultra-Sensitive Detection of Proteins in Chemiluminescent Western Blotting" •For high sensitivity chemiluminescent 1D & 2D immunoblotting (western blotting) imaging  VisionWorksLS Image Acquisition and Analysis Software  VisionWorksLS Image Acquisition and Analysis Software can be configured with the system or ordered separately. Check with your local representative for details. This sophisticated package provides comprehensive tools for image capture and analysis of gels, plates and membranes as well as colony counting. Capabilities include: •Image acquisition functions for simple image capture and expanded integration options •Apply numerous image enhancements to images •Comprehensive tools for advanced 1D lane densitometry and analysis including area density, molecular weights and colony counting •Support for 21 CFR Part 11 compliance •One-touch automated macros •Define user profiles and preferences •Generate extensive reports and export data •Multiple user network license available Technical Information Darkroom: •Light tight •Wide access door with UV safety shutoff •Gel viewing window •Sliding tray for transilluminator •Epi white and UV illumination (365nn and 480nm) Emission Filters - five positions: •SYBR Green 515-570nm •SYBR Gold 485-655nm •EtBr Red 570-640nm Software: •Interface for automated controls •VisionWorksLS (system may be configured with software or optional, check with your UVP representative) •Windows 2000 SP4, Windows XP Pro SP2 Transilluminators: •Select from FirstLight or Benchtop models (system may be configured with software or is optional, check with your UVP representative)     UVP BioLite Multispectral Source The BioLite Multispectral Source uses a 150 Watt quartz halogen visible light source with variable intensity and exchangeable filters for tightly controlling the output spectrum. The BioLite emits a consistent source for illumination of samples. Key Features: The six-position dial controls the light intensity output and has relative output levels from 8% to 100% The small footprint allows placement in the BioSpectrumAF Imaging System or other confined areas where laboratory space is minimal The unit is manufactured with a durable metal housing and scratch resistant powder paint The design eliminates light leakage for photosensitive applications Select from the optional interchangeable emission wavelength filters for examination of samples such as cultures and other specimens Fiber optic couplers for different sized fiber optic ferrules are available. Dimensions:  10D x 7W x 8.75H in. (254 x 483 x 222mm)  Weight: 9 lb (4 kg) Fiber Optic Ferrule Dimensions:  0.718 in. (18.2mm)                   Connecting to an Imaging System Connect the fiber optic bundles to the power supply through a port in the darkroom. The selectable intensity knob, interchangeable filter and power switch are conveniently located for easy access.       UVP Benchtop UV Transilluminators UVP's patented 3UV Benchtop Transilluminator provides the selection of longwave, midrange and shortwave in one compact unit. Key Features: Easily view gels under longwave for extended periods of time avoiding photonicking damage. Researchers can switch to midrange to increase the fluorescence for photodocumentation. Shortwave is used to irradiate samples. 2UV models provide longwave and midrange UV. All Benchtop Transilluminator models are compact, lightweight units. These 8-watt models provide a low cost alternative to the High Performance UV Transilluminators. A variety of filter area work surface sizes are available. Clear UV blocking cover included with each transilluminator. Dimensions:  11"D x 14"W x 5"H (279 x 356 x 143mm) Height includes UV blocking cover. WARNING: Transilluminators are powerful sources of ultraviolet radiation which can cause serious damage to unprotected eyes and skin. Read the ultraviolet Caution Information before operating any transilluminators.     UVP B100 Series High Intensity Ultraviolet Lamps   B-100SP High Intensity Lamp     The Blak-Ray B-100 Series high powered UV lamps offer brilliant irradiance for optimum fluorescence. All "P" series lamps come with the special heat-resistant plastic Cool-TouchTM housing which allows users to handle the lamp head regardless of how long the lamp has been operating.  These rugged lamps can be placed face down on a working surface without damamge to the filter.    Key Features: The B-100 lamp is recommended for use in leak detection applications Uses for the B-100AP and AP/R include science, non-destructive testing and fluorescence inspection The B100YP is excellent for semiconductor wafer inspection as most photoresist absorption occurs below 450nm 100 watt spot bulb is rated at 5000 hours. Bulb is standard in all lamps except the B-100SP Self-ballasted bulb included with the B-100SP has an average life of 450 to 2000 hours depending on use patterns Flood bulb may be used in all lamps (except B-100SP). Flood bulb life is estimated at 2000 hours Dimensions: B-100A: Lamp Head 8.5D x 5.5Dia. in. (216 x 140mm), Weight: 11.72lb (5.33kg) B-100AP: Lamp Head 9.75D x 6Dia In. (248 x 152mm), Weight: 12.5lb. (5.6kg) B-100AP/R: Lamp Head 9.75D x 6Dia In. (248 x 152mm), Weight: 12.5lb. (5.6kg) B-100SP: Lamp Head 9.75D x 6Dia. in. (248 x 152mm), Weight: 3.14lb. (1.43kg) B-100Y: Lamp Head 8.5D x 5.5Dia. in. (216 x 140mm), Weight: 11.72lb (5.33kg) B-100YP: Lamp Head 9.75D x 6Dia In. (248 x 152mm), Weight: 12.5lb. (5.67kg)                         B-100AP            B-100AP models feature a longwave UV and Cool-Touch housing, 100 watt longwave bulb and ballast base. At 18 in. (457 mm), the lamp produces a highly intense center of UV irradiance about 5 in. (127 mm) in diameter. Lamp head can rotate 360 degrees when attached to the base for hands-free operation or lamp can be removed from the base.  8 ft primary and secondary cords.                                      B-100YP B-100Y and B-100YP models feature a yellow filter which blocks wavelengths shorter than 500nm and produces three strong mercury lines at 543, 574 and 576nm. B-100Y is built with the aluminum housing; B-100YP plastic housing.                                 B-100A                 The longwave B-100A is manufactured with a scratch-resistant aluminum housing which connects to ballast base with an 8 foot cord; 8 foot secondary cord is included. The 100 watt longwave UV bulb is excellent for inspection applications.                    B-100AR B-100A/R - These longwave lamps feature 100 watts of power excellent for inspection applications. B-100A/R (shown)  offers  longer cord lengths - 20 foot (6.1m) primary and secondary cord lengths. B-100A/R is designed with the aluminum housing and same specification as B-100A.         UVP 3UV Ultraviolet Lamps   3UV Lamp    UVP’s innovative new 3UV lamp multi- wavelength (patented). The lamp houses longwave, shortwave and midrange 4, 6 or 8-watt UV tubes.    Key Features: Selection of each wavelength is by an easy turn of the dial located on one end of the housing The uniquely designed reflector surfaces mounted behind each tube provides maximum UV for fluorescence applications Lightweight and ergonomically designed for hand or stationary use Dimensions 3UV-34: 9.5L x 3W x 4.5D in. (241 x 76 x 114mm) 3UV-36: 12.5L x 3W x 4.5D in. (318 x 76 x 114mm)  3UV-38: 15.5L x 3W x 4.5D in. (394 x 76 x 114mm)
